ASTM A36 Hot Rolled Carbon Steel Sheet / Steel Plate/MS Sheet
Low Carbon Steel Plate
| Product Name | Hot rolled steel sheet |
| Thickness | plate:0.35-200mm strip:1.2-25mm |
| Length | 1.2m-12m or according to customer's special request |
| width | 610,760,840,900,914,1000,1200,1250mm |
| Tolerance | Thickness: +/-0.02mm, Width:+/-2mm |
| Material grade | Q195 Q215 Q235 Q345 SS490 SM400 SM490 SPHC SPHD SPHE SPHF SEA1002 SEA1006 SEA1008 SEA1010 S25C S35C S45C 65Mn SPHT1 SPHT2 SPH3 SPH4 QstE Others as your requirement |
| surface | iron gray (low carbon plate), brown (special alloy plate, the high carbon plate), partial ochre (weather resistance), with temperature oxidation pattern, than manufacture rough surface |
| Standard | ASTM,DIN,JIS,BS,GB/T |
| Certificate | ISO,CE, SGS,BV,BIS |
| Payment terms | 30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100% Irrevocable L/C at sight, 100% Irrevocable L/C after receive B/L 30-120 days, O/A |
| Delivery times | Delivered within 30 days after the receipt of deposit |
| Package | tied up with steel strips and wrapped with water proof paper |
| Application Range | Widely used in ship, automobile, Bridges, buildings, machinery, pressure vessels and other manufacturing industries |
| Advantages | 1. Reasonable price with excellent quality 2. Abundant stock and prompt delivery 3. Rich supply and export experience, sincere service |
Carbon Steel sheet used in an amount large class of materials, divided into ordinary low-carbon steel and special steel sheet,comprising
a high strength low alloy steel clad steel and corrosion resistant, and the like. Ordinary low-carbon steel plates are divided into two types:
cold-rolled and hot-rolled. Cold-rolled steel plates have good surface quality and accurate thickness dimensions.
They are mostly used to make car bodies. Hot-rolled plates are mostly used to make car frames and the like.
| Product name | carbon steel sheet |
| Thickness | cold-rolled:0.3-6mm hot-rolled:3-80mm |
| Length | 1.2m-12m or according to customer's special request |
| width | 610,760,840,900,914,1000,1200,1250mm |
| Tolerance | Thickness: +/-0.02mm, Width:+/-2mm |
| Material grade | Q195 Q215 Q235 Q345
SS490 SM400 SM490 SPHC SPHD SPHE SPHF
SAE1002 SAE1006 SAE1008 SAE1010
S25C S35C S45C
65Mn
SPHT1 SPHT2 SPH3 SPH4
QstE
Others as your requirement |
| surface | iron gray (low carbon plate), brown (special alloy plate, the high carbon plate), partial ochre (weather resistance), with
temperature oxidation pattern, than manufacture rough surface |
| Standard | ASTM,DIN,JIS,BS,GB/T |
| Payment terms | 30% T/T deposit in advance, 70% T/T balance |
| Product name | Carbon Steel Sheet A36 S235 S275 S355 Mild Carbon Steel Iron Hot Rolled Steel Sheet |
| Technique | Hot/Cold rolled |
| Surface | Black painted,galvanized,etc. |
| Thickness | 2B 2D BA(bright annealed) No.1 8K HL(Hair Line) PVC |
| Size | 6-400mm |
| Width | 1250-2500mm, 1250-2500mm |
| Length | 1000-12000mm, 1000-12000mm |
| Material | A36,SS400,A283 Gr.A,.Gr.B.Gr.C,A285 Gr.A,.Gr.B.Gr.C,Q235,Q195,Q215 |
| Certificate | ISO9001, CE |
| Special Use | High-strength Steel Plate, High-strength Steel Plate |
| Terms of payment | T/T,L/C at sight.etc. |
| Standard | AISI, ASTM, BS, DIN, GB, JIS |
| Type | steel plate, Boiler Vessel Plate |
| Package | Waterproof pater, steel strips packed Standard export package,suit for all kinds of transport,or as required. |
| Tolerance | ±1% |
| Processing Service | Bending, WELDING, Decoiling, Cutting, PUNCHING |
| Application | Steel plates are widly used as boiler plate, container plate, flange plate and ship plate, andwidly used in building construction. |
| Place of Origin | China |
| Grade | Q235 |
| Brand Name | LUYI |
| Model Number | A36,SS400,Q235,etc. |
We are professional steel coil supplier, have large stock steel coil. And can also customize produce special sizes depend on demands.
Stock steel coil material Q235B and Q345B, super fast delivery.
| Material | A36, SS400, Q345B, Q235B, Grade50, Q460 |
| Sizes | Thickness: 2MM-18MM | Width: 1250-2000MM | Length: 1250-11800MM |
| Fabrication service | Slit cut, average into smaller coil and so on |
ASME SA 516 GR.70-55 Chemical Composition: |
| Chemical Composition | Maximum C % for thickness t (mm) | Mn % for thickness t (mm) | Si % | P % max | S % max |
| 6-12.5mm | 12.5-25mm | 25-50mm | >50mm | ≤12.5mm | >12.5mm |
| ASME A516 Gr
55 | 0.18 | 0.2 | 0.22 | 0.25 | 0.55-0.98 | 0.60-1.30 | 0.13-0.45 | 0.035 | 0.035 |
| ASME A516 Gr 60 | 0.21 | 0.23 | 0.23 | 0.25 | 0.6-0.9 | 0.80-1.20 | 0.13-0.45 | 0.035 | 0.035 |
| ASME A516 Gr
65 | 0.24 | 0.26 | 0.26 | 0.28 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
| ASME A516 Gr
70 | 0.27 | 0.28 | 0.28 | 0.3 | 0.85-1.20 | 0.85-1.20 | 0.13-0.45 | 0.035 | 0.035 |
ASME SA 516 GR.70-55 Mechanical Property: | ASTM A36 Hot Rolled Steel Plate |
| Mechanical Property | Tensile
strength
(MPa) | Minimum
yield
strength
(MPa) | Minimum elongation (%) gauge length | Chemical Compostion | Mechanical Properties |
| 50mm | 200mm | Element | content | Mechanical Properties | Metric | Imperial |
| ASME A516 Gr
55 | 380-515 | 205 | 27 | 23 | Carbon, C | 0.25 - 0.290 % | Tensile Strength, Ultimate | 400 - 550 MPa | 58000 - 79800 psi |
| ASME A516 Gr 60 | 415 - 550 | 220 | 25 | 21 | Copper, Cu | 0.20% | Tensile Strength, Yield | 250 MPa | 36300 psi |
| ASME A516 Gr
65 | 450 - 585 | 240 | 23 | 19 | Iron, Fe | 98.0% | Elongation at Break (in 200 mm) | 20.0% | 20.0% |
| ASME A516 Gr
70 | 485 - 620 | 260 | 21 | 17 | Manganese, Mn | 1.03% | Elongation at Break (in 50 mm) | 23.0% | 23.0% |
| | | | | | Phosphorous, P | 0.040% | Modulus of Elasticity | 200 GPa | 29000 ksi |
| | | | | | Silicon, Si | 0.280% | Bulk Modulus (typical for steel) | 140 GPa | 20300 ksi |
| | | | | | Sulfur, S | 0.050% | Poissons Ratio | 0.26 | 0.26 |
| | | | | | | | Shear Modulus | 79.3 GPa | 11500 ksi |
products advantages
package:
| Package | Standard export seaworthy package,suit for all kinds of transport, or as required. |
| Water-proof Paper + Edge protection + Wooden Pallets |
| Bulk Size | Any size |
| Loading Port | Tianjin, Xingang Port, Qingdao,Shanghai, Ningbo, or any China Seaport |
| Container | 1*20ft container load Max. 25 Ton, Max. length 5.8m |
| 1*40ft container load Max. 25 Ton, Max. Length 11.8m |
| Delivery Time | 7-15 days or according to the order's quantity |
Shipping by 20 feet container, or 40 feet container or bulk vessel. If quantity too small, we can shipping by LCL(less than container to load)
Hot sales cold rolled mild steel sheet coils /mild carbon steel plate/iron cold rolled steel sheet price
we have large stocks for the carbon steel and low alloy steel plates and sheets, especially have the thick plate and heavy plates on stock, also can provide the special material and large size steel plates, boiler and pressure vessel steel plate, marine steel plate, hot rolled steel plate for new production. Tianjin Emerson Commercial and Trade Co., Ltd also has large stock for hollow bars, thick wall seamless pipes and tubes. Tianjin Emerson Commercial and Trade Co.,Ltd can provide good service for customer, good quality products, fast delivery, and after-sale service, Tianjin Emerson hopes to build good cooperation with everyone interested.
. How long will it take to execute my order?
A:Our normal lead time is 7-15 working days.,but we have many models in stock,We will let you know the estimated lead time after payment ASAP.
Q Can I have a sample for testing?
A: Free simples, you just need pay the freight.
Q. Do you have products in stock?
A: Because we only do wholesale, usually do not have stock, we provide fast shipping for most products, If there is any stock, we will inform you with details.
Q Do you have inspection procedures for the products?
A:100% self-inspection before packing
Q Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
