4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
Specifications
Brand Name :
WILLSTRONG
Model Number :
5318
Certification :
CE, TUV, ISO9001, PCT
Place of Origin :
China
MOQ :
600m2
Price :
7~20
Supply Ability :
10000000m2
Packaging Details :
Bulk packing or wood packages
Width :
1220mm, 1250mm, 1500mm
Alu. Alloy :
AA1100, AA3003
Coating :
PVDF / PET
Function :
Fireproofing, Anti-static, Anti-Bacterial
Panel Thickness :
3mm, 4mm, 5mm, 6mm
Alu. Thickness :
0.21mm, 0.3mm, 0.4mm, 0.5mm
Color :
WILLSTRONG, RAL, PANTON
Description

5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Composite Panel with 1220MM Width

Panel Thickness 2~4mm
Standard size 1220*2440mm
Aluminum Alloy AA1100, AA3003, AA5005
Core Layer PE, Aluminum honeycomb, fr, corrugated aluminum etc..
Width 1220mm, 1250mm, 1500mm, 1575mm
Length 2440mm, 3200mm, 4000mm, 5600mm
Weight subject to panel thickness
Surface on front side Polyvinylidene Fluoride (PVDF), FEVE, PET
Color ranges refer to WILLSTRONG color chart, or RAL/PANTONE/DULUX color series
Glossiness upon requirements
Back side finishes protective coating

Advantage of aluminum composite panel:

A. Light weight, good rigidity, high intensity, strong adhesion
B. Without any toxic materials, firepoof, anti-corrosion
C. Beautiful and delicate colors, good decorative effect
D. Easy to be fabricated to different sizes and shapes
E. Easy and fast installation, easy to recycle, no pollution.

Front side Aluminum-alloy sheet coated with flour-carbon resin (PVDF) OR PE roasting painting
Core Nontoxic polyethylene
Back side Aluminum-alloy sheet coated with polyester resin painting
Surface finish Treated with PVDF OR PE resin rolling roasting coating
Outside Protective carrier tape with brand logo

4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall

Usage:
A. Match any commercial or residential interior and exterior decoration

B. Widely used in ceiling, floor, bathroom, kitchen, cabinet, tunnel, subway, billboards, exhibitions, saloons, car, boat decoration, and more


Payment Details:
Payment Terms: T/T or L/C
Minimum Order: 600-1000 Square Meter (upon the various finish)
Delivery Details:
FOB Port: Shunde, Shenzhen, Guangzhou
Lead Time: 7 - 15 days after receipt of advanced payment & confirmation on color

Packing:
Strong wooden packing or bulk packing

REMARKS: OEM SERVICE IS AVAILABLE

Physical Data(Extraction from SGS Lab Report)
No. Test Item Result
1 Pencil Hardness 2H
2 Impact Resistance Impact failure end point:77.5kg.cm
3 Falling Sand Abrasion Litres of abrasive: 79.0L
Coating Thickness:1.1mil
Abrasion Resistance: 71.8L/mil
4 Specific Gravity 1.344
5 Shear Strength 21.8MPa
6 Heat Deflection Temperature 114.8 ºC
7 Peel Strength 0.98kg/mm
8 Flexural Modulus 14060MPa
9 Tensile Strength 35.1MPa
10 Elongation at break 13%

4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall4*8 feet 5318 Silver Metallic Color A2 / B1 Fireproof Aluminum Panel Curtain Wall
