Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Customized Thin Aluminum Strips High Tensile Strength AA1050/ AA1060/ AA1070
Specifications
Brand Name :
NOONDAY
Model Number :
AA1050/ AA1060/ AA1070
Certification :
RoHS/ISO9001/ASTM/JIS/GB/EN/ASTMB
Place of Origin :
China
MOQ :
5tons
Payment Terms :
L/C, T/T
Supply Ability :
50, 000 Mt Per Year
Delivery Time :
according to specification and quantity
Packaging Details :
Standard Export Packaging
Color: :
Sliver
Alloy States: :
AA1050/ AA1060/ AA1070
Surface Treatment: :
Mill finish
Technology: :
Rolling
Thickness: :
0.15mm-3.00mm
Width: :
20mm-850mm
Application: :
Power And Electrical Engineering Industrial Systems
Transport Package: :
Standard Export Packaging
Description

AA1050 Aluminium strip for transformer

Aluminium strip for transformer winding 1050-O


(1)Chemical Composition

Si Fe Cu Mn Mg Cr Zn Ti Others Al.
Individual Total
Max. 0.25 Max.
0.40		 Max.
0.05		 Max.
0.05		 Max.
0.05		 — Max.
0.05		 Max.
0.03		 Max.
0.03		 — Min. 99.50


(2)Mechanical properties and electric conductivity

Thickness(mm) Tensile Strength(Mpa) Elongation
%		 Bending 180 buckling inside radius Electric conductivity at 20
Over 0.3 to 0.5 Min. 60 Max. 90 20 min. Close contact 62.5 min.
Over 0.5 to 0.8 25 min.
Over 0.8 to 1.3 30 min.
Over 1.3 to 2.0 35 min.
Over 2.0 to 2.5 35 min


(3) Application :transformer strip for transformer winding 1050 can be used for variable transformer like low or high voltage transformer winding,etc.
transfer strip for electrical coil application ranges from 0.3mm to 2.5mm, the alloy 1050(99.50% aluminum) can be used to meet the minimum industry requirements for strip conductor, is closely controlled to assure smooth, substantially burr-free edges and strip-size availabilities are in capacities exactly equivalent to those of standard copper wire sizes.


Our advantages:
1, Since 2008, we have rich experience in this industry in China;
2, Good reputation in the production of aluminium/aluminum plate areas;
3, We start our productions from aluminum ingot,so we can control the quality as well;
4, We have our own development department for new material research;
5, Good experience and cooperation with big clients in the world;
6, With Certificate ISO9001-2008;
7, High performance cost ratio;
8, Fast delivery time;
9, Customized orders available;
10, Good communication skills, and good service and understandings for customers.
