High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA
Specifications
Brand Name :
NOONDAY
Model Number :
AA8011/ AA1100/ AA3102
Certification :
RoHS/ISO9001/ASTM/JIS/GB/EN/ASTMB
Place of Origin :
China
MOQ :
5tons
Payment Terms :
L/C, T/T
Supply Ability :
50, 000 Mt Per Year
Delivery Time :
according to specification and quantity
Packaging Details :
Standard Export Packaging
Color: :
Sliver
Alloy States: :
AA8011/ AA1100/ AA3102
Surface Treatment: :
Light Blue, Dark Blue, Golden, Special White
Technology: :
Rolling
Thickness: :
0.08mm-0.20mm
Width: :
150mm-1650mm
Application: :
Cooling Exchanger,air Conditioners Rediators
Transport Package: :
Standard Export Packaging
Description

High Performance Hydrophilic Aluminium Foil For Air Conditioning SGS TUV FDA​

Hydrophilic aluminum foil occupies 80% volume of the air conditioner aluminum foil, compared with aluminum finstock, the surface of the aluminum foil with corrosion-free and hydrophilic layer, therefore it brings the aluminum foil with function of corrosion-free, anti-mildew agent and no off-flavor; also compared with finstock aluminum foil, its cooling efficient increased 5%, therefore it is more idea air conditioner heat exchange material. It can reduce the noise, guarantee the long & steady hot exchanger results of the air conditioner.

Alloy: 1100/8011

Temper: H22, HO

Thickness: 0.08~0.2mm

width: 100~1500mm

Max. OD: 950mm max

ID:75mm,152mm, 200mm,300mm,500mm

Base Alloy Base temper thicknessmm Tensile strength σb MPa Requires non-proportional extension strength N/mm2 Elongation δ % Cupping Value IE mm
1050 1100 1200 0 0.095-0.220 85-110 ≥50 ≥20 ≥7.2
H22 100-130 ≥65 ≥18 ≥6.5
H24 115-140 ≥90 ≥16 ≥6.0
H26 125-155 ≥110 ≥10 ≥5.5
H18 ≥160 ≥2
8011 0 105-130 ≥50 ≥22 ≥7.5
H22 115-140 ≥65 ≥20 ≥7.2
H24 125-150 ≥90 ≥16 ≥6.5
H26 130-160 ≥110 ≥12 ≥5.8
H18 ≥180 ≥2
3102 H24 0.095-0.180 120-140 ≥100 ≥15 ≥6.0
H26 130-160 ≥110 ≥10

≥5.5

High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA High Performance Hydrophilic Aluminum Foil Width 150-1650mm SGS TUV FDA

Our advantages:
1, Since 2008, we have rich experience in this industry in China;
2, Good reputation in the production of aluminium/aluminum plate areas;
3, We start our productions from aluminum ingot,so we can control the quality as well;
4, We have our own development department for new material research;
5, Good experience and cooperation with big clients in the world;
6, With Certificate ISO9001-2008;
7, High performance cost ratio;
8, Fast delivery time;
9, Customized orders available;
10, Good communication skills, and good service and understandings for customers.
