AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
AL-PET Film Strip Cable Aluminum Foil , Aluminum Mylar For EMI Shielding
Specifications
Brand Name :
NOONDAY
Model Number :
Non Alloy
Certification :
RoHS/ISO9001/ASTM/JIS/GB/EN/ASTMB
Place of Origin :
China
MOQ :
5tons
Payment Terms :
L/C, T/T
Supply Ability :
50, 000 Mt Per Year
Delivery Time :
according to specification and quantity
Packaging Details :
Standard Export Packaging
Color: :
Sliver
Alloy States: :
AA8011/ AA8079/ AA1235
Surface Treatment: :
Mill finish
Technology: :
Rolling
Thickness: :
0.015-0.08mm
Width: :
2mm-530mm
Application: :
LED LCD screen, mobile phone, digital camera, DVD and other electronic equipments
Transport Package: :
Standard Export Packaging
Description

Aluminum Mylar For Cable Aluminum Foil Laminated With PET Film AL-PET Film Strip For Cable Wrapping For EMI Shielding

Product Description:

Aluminum mylar is made of aluminum foil and PET film, PET is also called mylar film or polyester film. The thicnkness of aluminum foil is 0.007mm to 0.1mm, and the thickness of PET film is from 0.004mm to 0.1mm, the PET film can strengthen the aluminum mylar tape's tensile strength, the aluminum foil are of good electrical conductivity, so it has good EMI shielding performance. Aluminum mylar is widly used in ethernet cable shielding such as CAT6 cable and CAT 7 cable and signal cable such as coaxial cable. It is also used in LED LCD screen, mobile phone, digital camera, DVD and other electronic equipments.

Product Name
Aluminum mylar
Material
Aluminum foil, polyester film, adhesive
Color
silver, gold, blue, pink, gray, yellow, black, and other customized color
Width
2mm-530mm
structure
AL-PET(single side); PET-AL-PET(double side)
Temperature
120℃

Commonly used specifications

specifications

Thickness(μm)

Al foil/mylar/glue

Total thickness

μm

tensile strength

kgf/mm2

elongation

%
15U
7/6/3
15±3
≥6
≥35
20U
7/12/3
20±3
≥6
≥35
25U
7/15/3
25±3
≥6
≥35
30U
7/19/3
30±3
≥6
≥35
38U
9/25/3
37±6
≥8
≥35
60U
35/25/3
63±8
≥6
≥35
75U
50/25/3
78±8
≥6
≥35

Our advantages:
1, Since 2008, we have rich experience in this industry in China;
2, Good reputation in the production of aluminium/aluminum plate areas;
3, We start our productions from aluminum ingot,so we can control the quality as well;
4, We have our own development department for new material research;
5, Good experience and cooperation with big clients in the world;
6, With Certificate ISO9001-2008;
7, High performance cost ratio;
8, Fast delivery time;
9, Customized orders available;
10, Good communication skills, and good service and understandings for customers.
