Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank
Specifications
Brand Name :
custom
Model Number :
Die Casting Cold Chambers for Die Casting Industry
Certification :
IATF 16949
Place of Origin :
China
MOQ :
1
Price :
USD50~USD7000
Supply Ability :
50PIECES EACH MONTH
Delivery Time :
3weeks
Packaging Details :
Wooden Carton suitable rough handle during transit
Item :
Die Casting Shot Sleeves for Die Casting Industry
Material :
1.2344,skd61
Surface Finish :
Rough Peeled,Fine Finishing
Material Conditions :
Annealed , Annealing
Hardness :
47~49HRC
Size :
From 100T to 3200T die casting machine
Material Quality :
Certificate available
Shot Sleeves :
Heat Treatment, Gas Nitridation
Material Shaped :
Forging Round Blank
Inside Diameter :
+0.035 -0
Description

Pressure Aluminium Die Casting Cold Chambers for Die Casting Industry

Product Description

The Durable Die Casting Cold Chambers /Plunger Tips/Plunger Rods Nozzles Adapters are the Critical Elements of the Aluminum Die Cast Process.

Features:

  • Tolerance of Die Casting Cold Chamber Inside Diameter: H7
  • Cold Chamber Length:885mm
  • Tolerance of Cold Chamber Outer Diameter:-0.1 -0.2
  • Precisionly Inside Diameter of Die Casting Cold Chamber for Die Casting Industry is to allow the appreciate velocities and pressure rise times.
  • Precisionly Fabricated Cold Chamber can optimize die casting process parameters in Die Casting Industry
  • Cheaped priced Die Casting Cold Chamber
  • Maximize the life of die casting Cold Chamber

Avaibable in: 3500T Shot Sleeve, 2800T Shot Sleeve, 1000T Shot Sleeve,
500T Shot Sleeve, 350T Shot Sleeve, 250T Sleeve, Integrated Shot Sleeve with or without Cooling Systems.

Material H13,1.2344,SKD61, Dievar, 4Cr5MoSiVi
Surface Finish Rough Peeled
Material Conditions Annealed, Annealing
Hardness 47~49HRC,477~475HB
Lifetime Over than 1year as per your requirement
Surface Treatment Gas Nitridation 0.2mm, Heat Treatment
Material Shaped Forging Forged
Other Shot System Components available 1. The cold chamber or shot sleeve
2. The plunger tip or shot tip
3. The shot cylinder
4. The plunger rod

Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank



Material Datasheet

Pressure Aluminium Die Casting Cold Chambers for Die Casting Industry


1.2344 is a hot work chromium-molybdenum-vanadium tool steel. It has excellent working properties and offers
high temperature strength and wear resistance.

  • Common 1.2344 Tool Steel Related Specifications

Country USA German Japan
Standard ASTM A681 DIN EN ISO 4957 JIS G4404
Grades H13 1.2344/X40CrMoV5-1 SKD61

  • 1.2344 Tool Steel Chemical Composition
ASTM A681 C Mn P S Si Cr V Mo
H13 0.32 0.45 0.2 0.6 0.03 0.03 0.8 1.25 4.75 5.5 0.8 1.2 1.1 1.75
DIN ISO 4957 C Mn P S Si Cr V Mo
1.2344 /X40CrMoV5-1 0.35 0.42 0.25 0.5 0.03 0.02 0.8 1.2 4.8 5.5 0.85 1.15 1.1 1.5
JIS G4404 C Mn P S Si Cr V Mo
SKD61 0.35 0.42 0.25 0.5 0.03 0.02 0.8 1.2 4.8 5.5 0.8 1.15 1 1.5



Why Choose Us?

  • Quality Certificate of Material Guaranteed;
  • Quality Sourced Finish Treatment Ensured ;
  • Competitively Priced Parts;
  • Delivered on time;
  • Located in Die Casting Industry Base In China;
  • Focus on Tooling & Mold Spare Parts;
  • More Than 7 Years` Experiences on Hardware;
  • These Die-Casting Machine Parts Are Used In Toshiba, Buhler, Ube, Lk, Yizhi Mi, Etc;
  • Mold Parts Equipped With The Production Of Automotive OEM Mold;
  • One Stop Solution;
  • Manufacturing Capacity of Shot Sleeves over 85pcs each Month;
  • Enjoy High Reputation Among Customers.

Package

Pressure Aluminium Die Casting Cold Chambers for Die Casting Industry

Industrial Aluminium Pressure Die Casting Cold Chambers Forging Round Blank



Contact

Attentions: Abel Li
Facebook: abel.li.102
Mob:+86 159 6803 7238;
Whatsapp:+86 159 6803 7238;

Facebook: abel.li.102;
Wechat: Abel-Mike;

Tel: +86 574 2688 6826;
Email: Abel.Li@jiaweidiecasting.com;
Add:No.600,Fuchunjiang Rd,Beilun,Ningbo,China 315800
Web: www.aluminumdiecasting-parts.com
