Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm
Specifications
Brand Name :
KALU
Model Number :
KALU-CZ-Aluminum-Plate-813
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
5 tons per Specification
Price :
usd 25000-40000 per ton
Payment Terms :
30% TT advance payment, balance paid before shipment
Supply Ability :
2000 tons per month
Delivery Time :
5-8 work days
Packaging Details :
Stretch film + non-woven fabric + wooden pallet
Welding method :
Friction stir welding
Material :
Aluminum alloy LF6
Normal width :
250mm, 380mm, Up to 600mm
LF6 Material Components :
Si 0.4%, Fe 0.4%, Cu 0.1%, Mn 0.8%, Mg 6.8%, Zn 0.2%, Ti 0.02%, Contaminants 0.15%, Al remain
Surface treatment :
Anodizing
Form of reinforcement :
Double-ball headband, Semi-ball headband, Square Tube Ribs
Max single profile width :
600mm
Max single profile length :
16200mm
Feature1 :
Good rust and corrosion resistance
Feature2 :
Good processability
Feature3 :
Good weldability
Feature4 :
Improving the performance of hull structures
Feature5 :
The tensile strength and elongation are higher than those of 6 series aluminum alloys
Feature6 :
Reduces environmental pollution from welding work and promotes environmental protection
Application1 :
Ambulance ships
Application2 :
Missile yachts
Application3 :
Corvettes
Application4 :
Destroyers
Application5 :
Fishery ships
Application6 :
Marine surveillance ships, Luxury yachts
Description

Product Detail

ZHANGJIAGANG KALU is one of the leading and reliable manufacturers and exporters of Ultra-wide Extruded Reinforced Sheet in China. We provide the high quality matched products and excellent services for various industries.
ZHANGJIAGANG KALU is one of the leading and reliable manufacturers and exporters of Ultra-wide Extruded Reinforced Sheet in China. We provide the high quality matched products and excellent services for various industries.
If you want to know more about our Ultra-wide Extruded Reinforced Sheet, please feel free to contact us, we will reply you within 24 hours.
Specification
Welding method Friction stir welding
Material Aluminum alloy LF6
Normal width 250mm, 380mm, Up to 600mm
LF6 Material Components Si 0.4%, Fe 0.4%, Cu 0.1%, Mn 0.8%, Mg 6.8%, Zn 0.2%, Ti 0.02%, Contaminants 0.15%, Al remain
Surface treatment Anodizing
Form of reinforcement Double-ball headband, Semi-ball headband, Square Tube Ribs
Max single profile width 600mm
Max single profile length 16200mm

Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm

Feature

Feature1 Good rust and corrosion resistance.
Feature2
Good processability.
Feature3
Good weldability.
Feature4 Improving the performance of hull structures.
Feature5 The tensile strength and elongation are higher than those of 6 series aluminum alloys.
Feature6 Reduces environmental pollution from welding work and promotes environmental protection.

Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm

Application

Application1 Ambulance ships
Application2 Missile yachts
Application3 Corvettes
Application4 Destroyers
Application5 Fishery ships
Application6 Marine surveillance ships
Application7 Luxury yachts

Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm

Technical Information

1

LF6 aluminum alloy ingot is pretreated, and the pretreated ingot is homogenized and annealed at 450-480°C for 12h, and then placed in the extrusion barrel of the extruder.

2

Heat the product mold in the extrusion cylinder to 450-500°C, control the temperature of LF6 aluminum alloy ingot to 380-410°C, control the temperature of extruder outlet to 300-340°C, and clamp the working table with the product mold and the extrusion cylinder.

3

The extrusion barrel in the extruder runs toward the product mold at an extrusion speed of 2.5-3.5m/min, extrudes the LF6 aluminum alloy ingot, and the LF6 aluminum alloy ingot is extruded out of the die hole of the product mold to obtain the LF6 aluminum alloy reinforced plate slat, in which the LF6 aluminum alloy ingot is heated by a segmented gradient heating method, and the head of the extruding barrel is heated at a temperature of 440-460°C, and the middle of the heating The head of the extrusion cylinder is heated at a temperature of 440-460°C, the middle is heated at a temperature of 440-460°C, and the tail is heated at a temperature of 370-390°C.

4

The LF6 aluminum alloy with ribbed plate slat made in step C is quenched, and the quenching method is the synchronous method of air cooling and atomized cooling, and the temperature of the quenched LF6 aluminum alloy with ribbed plate slat is 120-130°C.

5

The quenched LF6 aluminum alloy reinforced plate slat is subjected to aging heat treatment, the aging temperature is 180-220°C, and the aging time is 3-8h.

6

Welding for large width LF6 aluminum alloy strip plate.

Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mmUltra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm

Ultra Wide Extruded Reinforced Sheet Material Aluminum Alloy Lf6 Normal Width 250mm 380mm Up To 600mm

Packaging

ZHANGJIAGANG KALU Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.

1) ZHANGJIAGANG KALU Standard
2) Customization
