Specifications
Brand Name :
OEM
Model Number :
BF Series
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
30000 Rolls
Supply Ability :
6 containers per month
Delivery Time :
30-35 days after receiving 30% deposit.
Packaging Details :
Individually packing, 10 rolls shrinking a cylinder, 100rolls/ctn,120roll/ctn,150rolls/ctn,200roll/ctn
Product Code :
B150F
Product Name :
PVC Electrical Tpae, Vinyl Tape, Insulation Tape
Thickness :
0.15mm, 0.11mm - 0.18mm
Color :
Red, Blue, Yellow, Black, etc.
Width :
19mm - 50mm
Temperature Resistance :
80 ℃ (176℉)
Length :
9m - 25m
Application :
Wrapping electric wires
Rated voltage :
600 V
Description

PVC Electrical Tape - Non self-extinguishing

Descriptions:

A thin B grade plasticized soft PVC film coated with an aggressive pressure sensitive rubber based adhesive with good characteristics. It is highly confirmable and unaffected by most chemicals and moisture. It has been designed for electrical insulating application.

Flame Retardant 50mm PVC Electrical Tape Insulation

Technical Specification

Property Unit Product code Test method
B110F B120F B130F B150F B165F B180F
Total
Thickness		 mm 0.11 0.12 0.13 0.15 0.165 0.18 ASTM-D-1000
Tensile
Strength		 N/cm 16 16 18 20 22 25
Elongation
at break		 % 180 180 180 180 200 200
180°Peel
Adhesion to steel		 N/cm 1.3
To backing 1.3
Temperature
Resistance		 ℃ 80
Voltage
Resistance		 V 600 UL510

Flame Retardant 50mm PVC Electrical Tape Insulation

Standard Products

Flame Retardant 50mm PVC Electrical Tape Insulation

Flame Retardant 50mm PVC Electrical Tape Insulation
Applications:


For insulative connection and sheath protection of wire and cable under the voltage of 600V and on the environment temperature between 0°C~ 80°C, frame retardant.

Practical PVC insulating tape. The normal working temperature is 80°C, and when the temperature low to 0°C, it can working normally.

Primary electrical insulation
Protection for low and medium voltage cable splices
Colour coding
Industrial applications
Used for electrical cables wrapping in automotive application
Hand application

Flame Retardant 50mm PVC Electrical Tape Insulation

Features


Waterproof
Insulation, Flame retardant
High elongation
Widely application
Both outdoor, indoor, damp places not easy ooze water

Packaging & Shipping

Delivery: 30-35 days after receiving 30% deposit.
Packing Details: 1. Each roll packing with a label
2. 10 rolls shrink
3. 100rolls/carton, 120rolls/carton, 150rolls/carton, 200rolls/carton
According to customer's requests

Flame Retardant 50mm PVC Electrical Tape Insulation
Recommendations
Rolls should be stored flat on their cut edges in the original packaging. The products must be protected from dust, heat, moisture, direct sunlight and solvent fumes. The storage temperature should be between +10℃ and +25℃ x 65%R.H. Use within 12months of receipt. The tape should be applied with sufficient tension to ensure an optimum bonding and a minimum of two layers with a half overlap. The final layer should be wrapped with a lower tension to prevent flagging effects. Surfaces should be clean, dry and free of dust, grease, oil or other contaminants.
