Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Direct Cooling Steel 0.67A 250w Centrifugal Blower Fan
Specifications
Brand Name :
CBB
Model Number :
DF-3
Certification :
CE
Place of Origin :
Zhejiang
MOQ :
1 piece
Price :
USD70/piece
Payment Terms :
T/T, Western Union
Supply Ability :
2000 pieces per month
Delivery Time :
3-7 days
Packaging Details :
Plywood carton
Blade material :
Steel
Input :
AC 380V/Customized
Rpm :
2800
Power :
250W
Current :
0.67A
Flow :
504m³/hour
Cooling method :
Direct cooling
HS code :
8505200000
Description

Machine Cooling Centrifugal Blower Fan DF-3 DF3 250w 380V Input
Principle
DF series centrifugal fan can featured high pressure and low noise by the "multiple, forward, narrow" impellers. Widely used in printing, packaging, plastics, paper, glass, pharmaceuticals, footwear and other machiner and industrial. It can also be used for temperature, dust emission, cooling and so on. Air flow from blade channel flows into spiral volute, exhausts from air outlet after concentration and deversion.

Component

  • Motor
  • Steel impeller
  • Air inlet
  • Shell
  • Net cover
  • Other components

Specification

Model Type: DF-3 / Motor Type: YS 6322
Rated Voltag Frequency Rated Current Input Power Speed Air Flow Noise Static Pressure
(V AC) (Hz) (A) (W) (RPM) (m3/h) ≤Db (Pa)
380V 50 0.67 250 2800 504 75 620
Operation Mode Continuous operation
Direction of Rotation Counterclockwise (clockwise optional)
Mounting Position 4 direction
Bearing Ball bearing
Net weight 6.3kg
Blades Steel

Advantages

  1. The Fan with Compact structure.
  2. Dynamic balanced impeller.
  3. Small volume, light weight, angle adjustable and convenient for installation and maintenance.
  4. Fan Material is high quality steel.
  5. Customzation is acceptable.

Professional Manufacturing

1. Experienced engineers and R&D team to support the product technology & development.

2. Advanced manufacturing & inspection equipment, we have Laser cutting equipment, CNC equipment, Dynamic balance equipment, Air-flow/pressure/speed testing equipment.

3. Inspection. All products with serious inspection in hundred percent before delivery.

About CBB Chuangbo

Ruian Chuangbo Machinery Co., Ltd. established in 1995, is specialized in manufacturing of machinery parts. The company has advanced production level and scientific research equipment, the products are matched with printing, packaging, plastics, paper, textile, pharmaceutical machinery and other industries. The company has been granted with independent import and export rights, the products sold to allover the country and export to more than thirty countries and regions, such as: India, Pakistan, Israel, Russia, Spain and so on.
