Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Specifications
Brand Name :
Yongsheng
Model Number :
Aluminum Strip Coil
Certification :
ISO, RoHS
Place of Origin :
Zhengzhou Henan
MOQ :
1 ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 tons per month
Delivery Time :
7-25 days after order confirmation
Packaging Details :
Customized Packing
Product Name :
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Alloy :
1100 3003 8011
Temper :
O, H12, H14, H26, H22, H32, H34, H36, etc
Thickness :
0.015-1.5mm
Width :
800-1600mm
MOQ :
1 ton
Price terms :
FOB, CIF, CFR, CNF, etc.
Standards :
ASTM-B209,EN573-1,GB/T3880.1-2006
Description

Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip

  • Alloy/Grade: 1060 1100 3003 8011
  • Temper: O-H112, etc
  • Thickness: 0.015mm-1.5mm
  • Width: 800mm-1600mm
  • Length: As customer's requirement
  • Application: Aluminum-plastic composite pipe.

Product Description

Aluminum-plastic composite pipe is a pipe composed of a multi-layer structure, which is widely used in gas pipelines, water supply and drainage pipelines, heating pipelines and other fields. It consists of the following main parts:

  • Inner plastic pipe: usually made of materials such as polyethylene (PE) or cross-linked polyethylene (PEX), with good pressure resistance and anti-leakage.
  • Middle aluminum strip layer: made of high-purity aluminum alloy, the thickness is generally between 0.1-0.5mm. It plays a role in preventing leakage and enhancing mechanical strength.
  • Outer plastic pipe: also made of materials such as polyethylene or cross-linked polyethylene, providing protection and beautification.

Henan Yongsheng Aluminum Co. , Ltd . is located in Gongyi City Industrial Cluster Area , Henan Province . The factory focuses on the production and development of aluminum products such as Aluminum Strip , Color Aluminum , Aluminum Sheet , Aluminum Coil , Pressed Aluminum Product , Embossed Aluminum , and non-slip aluminum Sheet . The factory covers an area of 100 , 000 square meters , has 476 employees , has 20 casting processing production lines , 2 color coated aluminum coil production lines , 3 slitting production lines , 4 shearing production lines , 32 punch presses , 10 CNC lathes , 4 The embossed aluminum production line has an annual output of more than 200 , 000 tons , and exports account for more than 40%.

Product Specifications

Product Aluminum strip for multi layer pipes
Alloy 1050 1100 3003 3005 8006 8011
Thickness 0.015-1.5mm
Width 20-200mm
ID 150-152
OD 1000-1500
Technical Standard EN546

Alloy Temper Thickness(mm) Tensile Strength(Mpa) The Yield Strength(Mpa) Elongation(%) Hardness(HV)
1060
(1050)		 0 >0.2-0.5 60-100 ≥15 ≥20 20-30
>0.5-1.0 ≥30
>1.0-4.0 ≥35
H22 >0.2-0.5 80-120 ≥60 ≥12 30-40
>0.5-1.0 ≥15
>1.0-4.0 ≥18
H24 >0.2-0.5 95-135 ≥70 ≥6 35-45
>0.5-1.0 ≥8
>1.0-4.0 ≥10
H26 >0.2-0.5 110-155 ≥75 ≥2 43-55
>0.5-1.0 ≥4
>1.0-4.0 ≥6
H18 >0.2-0.5 ≥125 ≥85 ≥2 50-65
>0.5-1.0 ≥3
>1.0-4.0 ≥4
1100
(1200)		 0 >0.2-0.5 75-105 ≥25 ≥18 25-30
>0.5-1.0 ≥30
>1.0-4.0 ≥35
H22 >0.2-0.5 95-130 ≥75 ≥12 30-40
>0.5-1.0 ≥15
>1.0-4.0 ≥18
H24 >0.2-0.5 110-145 ≥95 ≥6 38-40
>0.5-1.0 ≥8
>1.0-4.0 ≥10
H26 >0.2-0.5 130-165 ≥115 ≥2 45-60
>0.5-1.0 ≥4
>1.0-4.0 ≥6
H18 >0.2-0.5 ≥150 ≥130 ≥2 55-70
>0.5-1.0 ≥3
>1.0-4.0 ≥4
3003
(3A21)		 0 > 0.2-0.5 95-140 ≥ 35 ≥ 15 30-40
> 0.5-1.0 ≥ 30
> 1.0-4.0 ≥ 35
H22 > 0.2-0.5 120-160 ≥90 ≥ 12 39-53
> 0.5-1.0 ≥ 15
> 1.0-4.0 ≥ 18
H24 > 0.2-0.5 145-195 ≥125 ≥ 6 42-59
> 0.5-1.0 ≥ 8
> 1.0-4.0 ≥ 10
H26 > 0.2-0.5 170-210 ≥150 ≥ 2 55-65
> 0.5-1.0 ≥ 4
> 1.0-4.0 ≥ 6
H18 > 0.2-0.5 ≥ 190 ≥ 170 ≥ 2 60-85
> 0.5-1.0 ≥ 3
> 1.0-4.0 ≥ 4
3004
(3104)		 0 > 0.2-0.5 155-200 ≥ 60 ≥ 13 49-62
> 0.5-1.0 ≥ 16
> 1.0-4.0 ≥ 20
H22 > 0.2-0.5 190-240 ≥ 145 ≥ 10 60-84
> 0.5-1.0 ≥ 12
> 1.0-4.0 ≥ 14
H24 > 0.2-0.5 220-265 ≥ 170 ≥ 8 68-100
> 0.5-1.0 ≥ 10
> 1.0-4.0 ≥ 12
H26 > 0.2-0.5 240-285 ≥ 190 ≥ 3 72-110
> 0.5-1.0 ≥ 4
> 1.0-4.0 ≥ 6
H18 > 0.2-0.5 ≥ 260 ≥ 230 ≥ 2 85-120
> 0.5-1.0 ≥ 2
> 1.0-4.0 ≥ 3
3005 0 >0.2-0.5 115-165 ≥45 ≥13 35-45
>0.5-1.0 ≥20
>1.0-4.0 ≥25
H22 >0.2-0.5 145-195 ≥110 ≥10 40-60
>0.5-1.0 ≥15
>1.0-4.0 ≥15
H24 >0.2-0.5 170-215 ≥130 ≥6 58-70
>0.5-1.0 ≥8
>1.0-4.0 ≥10
H26 >0.2-0.5 195-240 ≥160 ≥3 65-83
>0.5-1.0 ≥4
>1.0-4.0 ≥6
H18 >0.2-0.5 ≥220 ≥200 ≥2 80-100
>0.5-1.0 ≥3
>1.0-4.0 ≥3
3105 0 >0.2-0.5 75-105 ≥25 ≥14 32-42
>0.5-1.0 ≥20
>1.0-4.0 ≥25
H22 >0.2-0.5 95-130 ≥75 ≥10 39-60
>0.5-1.0 ≥12
>1.0-4.0 ≥12
H24 >0.2-0.5 110-145 ≥95 ≥8 52-62
>0.5-1.0 ≥10
>1.0-4.0 ≥10
H26 >0.2-0.5 130-165 ≥115 ≥3 58-72
>0.5-1.0 ≥4
>1.0-4.0 ≥6
H18 >0.2-0.5 ≥150 ≥130 ≥2 65-95
>0.5-1.0 ≥2
>1.0-4.0 ≥3
5005 0 >0.2-0.5 100-145 ≥35 ≥15 33-43
>0.5-1.0 ≥20
>1.0-4.0 ≥25
H22 >0.2-0.5 125-165 ≥80 ≥12 30-53
>0.5-1.0 ≥15
>1.0-4.0 ≥18
H24 >0.2-0.5 145-185 ≥110 ≥8 40-60
>0.5-1.0 ≥10
>1.0-4.0 ≥10
H26 >0.2-0.5 165-205 ≥135 ≥3 50-68
>0.5-1.0 ≥4
>1.0-4.0 ≥6
H18 >0.2-0.5 ≥185 ≥165 ≥2 57-68
>0.5-1.0 ≥2
>1.0-4.0 ≥3
5052
(5251)		 0 > 0.2-0.5 170 - 215 ≥ 65 ≥ 14 50 - 70
> 0.5-1.0 ≥ 17
> 1.0-4.0 ≥ 20
H22 > 0.2-0.5 210 - 260 ≥ 130 ≥ 8 70 - 85
> 0.5-1.0 ≥ 10
> 1.0-4.0 ≥ 10
H24 > 0.2-0.5 230 - 280 ≥ 150 ≥ 4 80 - 110
> 0.5-1.0 ≥ 6
> 1.0-4.0 ≥ 6
H26 > 0.2-0.5 250 - 300 ≥ 180 ≥ 2 85 - 115
> 0.5-1.0 ≥ 4
> 1.0-4.0 ≥ 6
H18 > 0.2-0.5 ≥ 270 ≥ 240 ≥ 2 　
> 0.5-1.0 ≥ 2
> 1.0-4.0 ≥ 3

Product Show

Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip

Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip

Aluminum-plastic Composite Aluminum Strip 1100 3003 8011 Aluminium Alloy Strip
