Specifications
Place of Origin :
Shenzhen, China.
Brand Name :
AMEISON
Model Number :
AMXP-3338S-D18L65
Certification :
RoHS and REACH Compliant by Exemption
Polarization :
±45º
Gain（dBi） :
2×17.5
VSWR :
≤1.5
Lightning protection :
DC Ground
Input connector type :
2-N Female
Price :
FOB SHENZHEN
Packaging Details :
bubble PP bag or EPE/inner box/master carton(safe export packaging)
Delivery Time :
10 days
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
80,000 Pieces per Month
MOQ :
500 pcs per item
Frequency Range :
3300～3800MHz
Type :
External
Description

3300-3800MHz Directional Panel Antenna

AMXP-3338S-D18L65

Feature:

High gain

Full day working

Optimized dimension

Dual polarization

Application:

3.3G～3.8G wireless access coverage

AMXP-3338S-D18L65

Electrical Specifications

Frequency range(MHz)

3300～3800

Polarization

±45º

Gain(dBi)

2×17.5

Half-power beam width(°)

H:65 V:7

Front-to-back ratio(dB)

≥25

Input Impedance(Ω)

50

VSWR

≤1.5

Isolation between ports

≥28dB

Cross-polar ratio

≥15dB@0º ≥10dB@+/-60º

Sidelobe suppression for first sidelobe above horizon

15 dB

Maximum input power(W)

200

Lightning protection

DC Ground

Mechanical Specifications

Input connector type

2-N Female

Dimensions-mm (Height/Width/Depth)

760*114*54

Packing size(mm)

800*155*145

Antenna weight (kg)

3.6

Radome material

UPVC

Radome color

Gray

Mechanical tilt(°)

0～10

Operating temperature(°c)

-40～60

Rated Wind Velocity(m/s)

60

Mounting hardware(mm)

￠35～￠75
