806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
806-960/1710-2500MHz 5dBi Omni Ceiling Mount DAS Antenna GSM CDMA PCS 3G WLAN antenna
Specifications
Place of Origin :
Shenzhen, China.
Brand Name :
AMEISON
Model Number :
AMXC-8025-5A
Certification :
RoHS and REACH Compliant by Exemption
Frequency range（MHz） :
806～960/1710～2500
Bandwidth（MHz） :
154/790
Gain（dBi） :
3/5
VSWR :
≤1.5
Polarization :
Vertical
Lightning protection :
DC Ground
Input connector type :
N Female
Mounting way :
fastened with screw nuts
Price :
FOB SHENZHEN
Packaging Details :
bubble PP bag or EPE/inner box/master carton(safe export packaging)
Delivery Time :
10 days
Payment Terms :
L/C,T/T,Western Union,MoneyGram,PayPal
Supply Ability :
80,000 Pieces per Month
MOQ :
500 pcs per item
Description

806-2500 MHz Omni Ceiling Mount Antenna

Factory price

Attractive unobtrusive radome design

DAS (Distributed Antenna System)

806-2500MHz Indoor Omnidirectional Camouflage Ceiling Antenna

AMXC-8025-5A

Feature:

Exquisite appearance

Suitable for ordinary ceiling mounting

Wide frequency band

Low standing wave

Strong anti-interference ability

Application:

Indoor omnidirectional coverage

GSM/CDMA/PCS/3G/WLAN system

AMXC-8025-5A

Electrical Specifications

Frequency range(MHz)

806～960/1710～2500

Bandwidth(MHz)

154/790

Gain(dBi)

3/5

Half-power beam width(°)

H:360 V:55/30

VSWR

≤1.5

Input Impedance(Ω)

50

Polarization

Vertical

Maximum input power(W)

50

Lightning protection

DC Ground

Input connector type

N Female

Mechanical Specifications

Dimensions(mm)

Φ170*70

Antenna weight(kg)

0．35

Operating temperature(°c)

-40～60

Radome material

ABS

Radome color

white

Mounting way

fastened with

screw nuts
