Specifications
Brand Name :
ANC or customized
Model Number :
ODVA SC
Certification :
RoHS
Place of Origin :
China
MOQ :
1pc
Price :
please ask
Payment Terms :
T/T, Western Union
Supply Ability :
3000pcs terminator per day
Delivery Time :
5-10 working days
Packaging Details :
1pc per bag
Connector A :
ODVA SC or custom
Connector B :
SC or ODVA SC or custom
Fiber Type :
SM, OM1, OM3, OM4 or custom
Cable Diameter :
4.8mm or 7.0mm or custom
Armored :
with or without optional
Insertion Loss :
<0.30dB
Return Loss :
>50dB for SM/PC; >60dB for SM/APC
Length :
5m, 10m, 20m or custom
Description

ODVA SC Fiber Optic Patch Cord Outdoor IP67 Simplex or Duplex 10m 30m 50m

Description

Outdoor ODVA SC Fiber Optic Patch Cord manufactured by ANC International Co., Limited is available in both single mode and multimode version, this ODVA SC is a typical outdoor use fiber cable, suitable for different temperature and weather, especially ideal for FTTA and harsh environment use. The ODVA SC fiber optic patch cords are offered with bayonet-locking connectors with low cost rugged plastic shells to provide a quick mating interconnect solution. ANC offers ODVA-LC patch cords, ODVA-SC patch cord, ODVA-MPO patch cords as per customer requests, length from 1Meter to 500Meters. All assemblies come with an ODVA connector on one end and an LC, SC, MPO or ODVA style connector on the other end. The cable core can be simplex, duplex, 4-core, 6-core, 8-core, 12-core or custom.

Features

Both single mode and multimode version optional
One-hand mating

Bayonet style locking mechanical

With a rugged and armored PU/LSZH jacketed cable
Cable Diameter: 4.8mm or 7.0mm or other specified
Easy and safe intallation
Water proof, dust proof and corrosion resistant
Meet IP67 Standards
RoHs compliant
Cable Length: 1M 2M 10M 30M 100M or specified

Low insertion loss and high return loss

OEM and ODM customized production

Applications

Widely used in FTTA & FTTH

For connection between distribution box and RRH
Deployment in Remote Radio Head cell tower applications

Used for 3G 4G base station

BBU, RRU, RRH, LTE

ODVA Fiber Optic Patch Cord Drawing

ODVA SC Fiber Optic Patch Cable Outdoor IP67 Simplex Duplex 10m 30m 50m Length

Other Cable Structure is also optional upon request

Type1: 2×Tight Buffer(0.9mm)+Kevlar+Jacket OD=4.8mm;
Type2: 2×Tight Buffer(0.9mm)+Kevlar+Spiral +Jacket OD=4.8mm
Type3: 0.9mm tight buffer*2 +2.0mm Jacket*2 +2×2.0mm Tube+Jacket OD=7.0mm;
Type4: 0.9mm tight buffer*2 +2.0mm Jacket*2 +2×2.0mm Tube+power cable 0.75M2 *2 Jacket OD=8.5.0mm;

ODVA SC Fiber Optic Patch Cable Outdoor IP67 Simplex Duplex 10m 30m 50m Length

Technical Data

Parameters Standard Fiber Cable Assemblies
Connector Side-A ODVA SC Connector or custom
Side-B DLC(duplex LC),SC,ST,FC,MPO/MTP
Fiber count 1F or 2F or 4F......24F
Fiber Type SM(G.652D/G.657A) MM(OM1/OM2/OM3)
Jacket Materials LSZH/OFNR/PVC/PE
Ferrule Materials Ceramic
Testing Wavelengths 1310±30/1550±30nm 850±30/1300±30nm
Insertion Loss(dB) ≤ 0.3dB ≤ 0.3dB
Return Loss(dB) ≥50dB(PC/UPC); ≥60dB(APC) ≥35dB(PC/UPC)
Exchange ability ≤ 0.2dB
Cable Assemblies Pigtail/Simplex/Duplex/Fan-out Patchcord
Operating Temperature (° C) 10~ + 70
Storage Temperature (° C) -40 ~ +85

ODVA SC Patch Cord Related Pictures

ODVA SC Fiber Optic Patch Cable Outdoor IP67 Simplex Duplex 10m 30m 50m Length

ODVA SC Fiber Optic Patch Cable Outdoor IP67 Simplex Duplex 10m 30m 50m Length

ODVA SC Fiber Optic Patch Cable Outdoor IP67 Simplex Duplex 10m 30m 50m Length
