SMA Female Hybrid Fiber Optic Adapters Simplex SM MM Fiber Optional
SMA Female Hybrid Fiber Optic Adapters Simplex SM MM Fiber Optional
SMA Female Hybrid Fiber Optic Adapters Simplex SM MM Fiber Optional
SMA Female Hybrid Fiber Optic Adapters Simplex SM MM Fiber Optional
Specifications
Brand Name :
ANC
Model Number :
FC Male to SMA Female Adapter
Certification :
RoHS
Place of Origin :
China
MOQ :
1pc
Price :
please ask
Payment Terms :
T/T, Western Union
Supply Ability :
3000pcs per day
Delivery Time :
3-5 working days
Packaging Details :
1pc/bag
Fiber Type :
SM, OM1, OM2, OM3, or customized
Housing :
Metal
Type :
Simplex
Insertion Loss :
≤0.3dB
Connector A :
FC Male
Connector B :
SMA Female
Packing :
1pc/bag
HS Code :
8536700000
Description

SMA Female Hybrid Fiber Optic Adapters Simplex SM MM Fiber Optional

Description of SMA Female to FC Male Hybrid Fiber Optic Adapters

FC Male to SMA Female Fiber Optic Adapters manufactured by ANC International Co., Limited is a regular type fiber-embedded adapter. The fiber used inside can be SM, OM1, OM2, OM3, OM4 or other customized. This hybrid FC Male to SMA Female adapter inexpensively adapt connector interfaces to new equipment, upgrade distribution panels and eliminate the need to re-terminate cable assemblies. Fiber optic adapter, sometimes also called coupler, is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines. These hybrid FC Male to SMA Female adapters change the existing SMA connector on your equipment into a regular FC connector. The female to male fiber adapters have embedded fiber and ceramic sleeves inside to make precise connection.

This FC male to SMA female Hybrid Fiber Optic Adapter, is a mating sleeve that is designed for connecting together a SMA male connector into a FC male port.

Specification of SMA Female to FC Male Hybrid Fiber Optic Adapters

Hybrid adapter type: SMA (Female) to FC(Male)
Fiber type: SM 9/125 Fiber or MM 50/125 or MM 62.5 or customized
Insertion Loss(db): Less than 0.30
Repeatability(db): Greater than 0.20
Interchangeability(db): Less than 0.20
Working temperature: -25C to +75℃
High precision instrument

High interface performance

High return loss

Easy to handle

Environmentally stable

Usage

FTTx

Telecommunication Networks

Ethernet Networks

Optical Communication Equipment

CATV Networks

Local Area Networks

Specifications of SMA Female to FC Male Hybrid Fiber Optic Adapters

Item Parameter
Single Mode (SM-9/125) Multi Mode(MM-50/125) or
Multi-Mode(MM-62.5/125)
Insertion Loss ≤0.3dB
Durability (500 Mating) 0.2dB Max.
Operating Temperature -40℃~+75℃
Storage Temperature -40℃~+85℃
Remark: FC Male to SMA Female Hybrid Fiber Optic Adapte is ultra reliable components featuring low insertion loss and back reflection loss. You can select singlemode 9/125um or multimode 62.5/125um or multimode 50/125um.


Optical Performance

　 Premium Grade Standard Grade
Insertion Loss ≤0.2dB ≤0.3dB
Durability 500 times 500 times

Environment and Mechanical

Properties Test condition Compliant Test result
Vibration 10-55Hz, 1.5mm, 60min IEC61300-2-1 ≤0.2dB
Mating Durability 1000 Mating, clean every 25 mating. IEC61300-2-2 ≤0.2dB
Impact 1.5m, 8 drops IEC61300-2-6 ≤0.2dB
Strength of Coupling Mechanism 40N, 10Min, L=22-28cm IEC61300-2-12 ≤0.2dB
Temperature Cycling 40ºC to +75ºC, 40 cycles IEC61300-2-22 ≤0.2dB
Temperature humidty cycling 40ºC, 95%, 96Hr IEC61300-2-21 ≤0.2dB
Operating Temperature -40ºC to +85ºC 　 ≤0.2dB
Storage Temperature -40ºC to +85ºC 　 ≤0.2dB
