DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
Specifications
Brand Name :
ANC
Model Number :
DIN-DIN
Certification :
RoHS
Place of Origin :
China
MOQ :
10pcs
Price :
please ask
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs per day
Delivery Time :
5-7 working days
Packaging Details :
25pcs per box
Material :
Metal
Shape :
thread or rectangle
Insertion Loss :
<0.2dB
Sleeve :
Ceramic
Type :
UPC, APC universal
Dust cap color :
red or customized
Description

DIN to DIN Simplex Fiber Optic Adapters Singlemode and Multimode Metal Body

Description

DIN-DIN Fiber Optic Adapter manufactured by ANC International Co., Limited is used to join two fiber optic patch cables together. It contains the interconnect sleeve, that holds the two ferrules together. DIN fiber optic adapter is available in single mode UPC APC and multimode SPC to sastify to connect single mode or multimode patch cable. Fiber optic adapters are used to provide a cable to cable or cable to equipment fiber optic connection. We supply a wide range of mating sleeves and hybrid adapters, including special male to female hybrid fiber optic adaptor.

Specification

Low insertion loss, high return loss

Good compatibility

High precision of mechanical dimensions

High reliability & stability

Ceramic sleeve

DIN style to DIN style
Use in Singlemode or Multimode applications.
Free-hanging or panel-mount design.
Dust caps protect against debris and contamination
RoHS Compliant

Features

High Precision Alignment

compliant with the IEC and ROSH standards

Usage

Optical Fiber Communications,Video,LAN, CATV Systems
Optical Network Equipments,optical Test Equipments
Module Pigtails,Multi media,Premise
Active device termination installations

Technical Data

Item Parameter
Connector Type DIN-DIN
Fiber Type Singal mode or Multimode
Adapter Color Metal
Testing Wavelength 1310nm,1550nm or 850nm
Typical Insertion loss ≤0.15dB
Maximum Insertion loss ≤0.20dB
Repeatability ≤0.10dB
Exchangeability ≤0.20
Durability 1,000 Mating, loss≤0.20dB
Channel Number Singal core
Frame Material Metal
Sleeve Material(Customized) Default ceramics(Zr02)
Operating Temperature -20℃~ + 70℃
Storage Temperature -40 ℃~ + 85℃


Related Products Pictures

DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB

DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB

DIN To DIN Simplex Fiber Optic Adapters Singlemode Multimode Metal Body 0.2dB
