5 Inch IP65 Rugged Pda RFID Scanner Mobile Computer 2D QR Reader RFID NFC Handheld Terminal Data Collector

Data Collector NFC Rugged Pda scanner mobile computer 2D QR reader RFID handheld terminal data collector

Description

• 1D/2D Barcode Scanning Engine
• It can be equipped with high-performance 1D/2D barcode professional scanning engine, which can quickly and accurately identify barcodes and facilitate item management
• Octa-Core CPU
• Brilliant operation provided by Octa-Core CPU MTK MT6765 Cortex-A53, Frequency 2.3GHz
• 4G Netcom
• Support 4G Netcom, Bluetooth 4.0+EDR,2.4G+5G Wi-FiStable Data Transition

• Specification

• Basic Configuration	CPU	MTK6765Contex-A53 Octa-cores, 2.3GHz
  	OS	Android 12.0
  	Memory	4GB RAM + 64GB ROM
  	Extended Memory	Support maximum 512GB extended MicroSD (TF) card
  	Display	5 inches IPS screen, LED backlight, 720*1280
  	Touch Screen	5-point capacitive touch screen
  	Wi-Fi	IEEE 802.11/a/b/g/n, 2.4GHz + 5GHz Dual-Frequency
  	Blue tooth	Blue tooth V5.0+EDR
  	GPS	Support GPS+Glonass+AGPS positioning
  	Camera	8.0MP(AF) with flash led
  	Mobile Communications	Support 4G-LTE | 3G | 2G GSM:B5/850;B8/900;B3/1800;B2/1900;3G:WCDMA B1/2100;B2/1900;B5/850;B8/900;FDD: B1/B3/B7/B20 TDD: B38/B39/B40/B41
  	Battery capacity	4000mAh rechargeable polymer lithium battery
  	G-Sensor	Support
  	Light Sensor	Support
  	Vibrating alert	Support
  	Volume	Loud speaker volume, easy to deal with noisy environment
  	Expansion slot	Micro SD(TF)*1, Micro SIM*2
  	Interfaces	USB Type-C *1
  Mechanical Specifications	Dimension	165mm(length)*76mm(width)*16mm(thickness)
  	Net Weight	265g (including 4000mAh battery, without UHF RFID)
  Protection Grade	IP65, 6 sides could undertake the impact by falling from 1.5m to the cement ground for may times within the scope of operating temperature
  Standard Parts	Charger *1, USB Cable *1
  Optional Features	UHF RFID	Regulatory: FCC (NA, SA) 917.4 – 927.2 MHz ETSI (EU) 865.6 – 867.6 MHz TRAI (India) 865 – 867 MHz KCC (Korea) 917– 923.5 MHz MIC (Japan) 916.8 – 923.4 MHz ACMA (Australia) 920 – 926 MHz SRRC-MII (P.R.China) 920.1– 924.9 MHz ‘Open’ (Customizable channel plan;859 – 873 MHz and 915 – 930 MHz) RFID Protocol: EPCglobal Gen 2 (ISO 18000-6C) Read distance: 0~5m Performance: Up to 200 tags/sec reading 96-bit EPC Output range: Separate read and write levels, commandadjustablefrom 0 dBm to +27 dBmin 1 dB steps
  	2D Barcode Reader	1D: Code 39, Codabar, Code 128, Discrete 2 of 5,Interleaved 2 of 5, Code 93, UPC-A, UPC-E, EAN-8, EAN-13, MSI, EAN-128, ISBN/ISSN, etc. 2D: PDF417, Micro PDF417, QR Code, Micro QR,MaxiCode, Data Matrix, GS1 Composite, Australian Post, British Post, Canadian Post, Japanese Post, etc.

• Picture detial

•

• Application

  1D/2D Barcode Scanning Engine

• It can be equipped with high-performance 1D/2D barcode professional scanning engine, which can quickly and accurately identify barcodes and facilitate item management.

•

• FAQ.

• 1. Can you introduce your company and products?

  Founded in 2003, it is located in Shenzhen, with a plant area of 5,000 square meters and more than 150 employees. We have 14 years of experience in touch screen development and manufacturing, achieving a daily output of 5000pcs and an annual global shipment of more than 1 million units. Our products are sold to more than 30 countries and regions. For more product information, please contact our sales manager online.

  2. What is the MOQ of your products?

  We can provide 1 unit for sample order. There are small quantities in stock. If you need discounts for bulk orders, please feel free to contact our online sales manager.

  3. What payment methods does your company accept?

  We accept most payment methods, and prefer T/T, Alipay.

  4. What is your logistics transportation method? What's the shipping cost and delivery date?
  Usually 5 days for samples, 30 days for mass production.

  5. What is your product packaging scheme? Is it reliable?
  The package is solid packaging containing a quality product that has passed inspection and drop testing. We guarantee to deliver your goods in good condition.
