36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
Specifications
Brand Name :
ANENpower
Model Number :
APM24E
Certification :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Place of Origin :
Shenzhen
MOQ :
500pcs
Price :
Please contact our Sales
Payment Terms :
50% deposit, 50% before dispatch
Supply Ability :
500,000.00pcs/month
Delivery Time :
18~25 working days after receiving the deposit
Packaging Details :
PE bag / White box / Custom made
Input Range :
100 ~ 240Vac, 50 / 60Hz
Power Range :
15 ~ 24W
Certificates :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Application :
Breath Detectors/testers, ECG, EEG, Portable Medical Devices, Medical Tablets, Digital Blood Pressure Monitors, Etc.
MTBF :
100,000 Calculated Hours
Case Size :
76L x 43W x 30H (mm)
Description

36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply

The 36W SMPS Medical AC Adapter is designed for safe and efficient power supply in medical applications. This versatile adapter supports multiple output voltages of 5V, 12V, and 24V, making it suitable for a wide range of medical devices. With its IEC/EN 60601 and CE GS certifications, you can trust that this power supply meets the highest safety and performance standards.

  • Safety Certifications: Compliant with IEC/EN 60601 and CE GS standards, ensuring safe operation for medical equipment.
  • Multiple Voltage Outputs: Offers versatile output options of 5V, 12V, and 24V, making it ideal for various medical applications.
  • Compact Design: Lightweight and compact, this adapter is easy to transport and suitable for both stationary and mobile use.
  • High Efficiency: Engineered with switch-mode technology, providing high efficiency and reducing heat generation during operation.
  • Reliable Performance: Built to deliver consistent and stable power to medical devices, enhancing their performance and reliability.

This 36W SMPS Medical AC Adapter is an essential component for healthcare professionals, ensuring that medical devices receive safe, reliable power for optimal patient care.

• Power Range: 16~36W

• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, E:EU, K:UK, A: AU
• Output voltage available from 5~48 VDC

• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 76L x 43W x 30H (mm)
• Weight: 200g

Model NO. MAX OUTPUT POWER OUTPUT VOLTAGE MIN LOAD MAX LOAD LOAD REGULATION LINE REGULATION RIPPLE & NOISE
APM24EA 16W 5-8V 0A 2.0A ±5% ±1% 100mV
APM24EB 18W 5-8V 0A 3.0A ±5% ±1% 100mV
APM24EC 20W 5-8V 0A 4.0A ±5% ±1% 100mV
APM24ED 24W 9-11V 0A 1.5A ±5% ±1% 250mV
APM24EE 27W 9-11V 0A 2.0A ±5% ±1% 250mV
APM24EF 20W 9-11V 0A 3.0A ±5% ±1% 250mV
APM24EG 30W 12-17V 0A 1.66A ±5% ±1% 250mV
APM24EH 24W 12-17V 0A 2.5A ±5% ±1% 250mV
APM24EJ 30W 18-24V 0A 1.33A ±5% ±1% 350mV
APM24EK 30W 18-24V 0A 1.66A ±5% ±1% 350mV
APM24EL 20W 36-48V 0A 0.55A ±5% ±1% 480mV
APM24EM 30W 36-48V 0A 0.83A ±5% ±1% 480mV
APM24EN 36W 12V 0A 3.0A ±5% ±1% 250mV
APM24EP 24W 12V 0A 2.0A ±5% ±1% 250mV
APM24EQ 36W 24V 0A 1.5A ±5% ±1% 350mV
NOTED:
1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
3 : Max. Power (W) = Vo x Io

36W SMPS Medical AC Adapter 5V 12V 24V IEC/EN 60601 CE GS Certified EU Plug Power Supply
