UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
Specifications
Brand Name :
ANENpower
Model Number :
APM19U
Certification :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Place of Origin :
Shenzhen
MOQ :
500pcs
Price :
Please contact our Sales
Payment Terms :
50% deposit, 50% before dispatch
Supply Ability :
500,000.00pcs/month
Delivery Time :
18~25 working days after receiving the deposit
Packaging Details :
PE bag / White box / Custom made
Input :
100 ~ 240Vac, 50 / 60Hz
Power Range :
15 ~ 24W
Certificates :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Application :
Breath Detectors/testers, ECG, EEG, Portable Medical Devices, Medical Tablets, Digital Blood Pressure Monitors, Etc.
MTBF :
100,000 Calculated Hours
Case Size :
60.5L x 39W x 34H(mm)
Description

UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug

The UL 60601 Certified 12V 2A Medical Grade AC Adapter is a reliable power solution designed for medical applications. With a 5V and 24V switching power supply, this adapter features a US plug for easy integration into healthcare settings.

  • Safety Certified: Complies with UL 60601 standards for medical device safety.
  • Versatile Output: Delivers stable 12V 2A power and supports 5V and 24V outputs, suitable for various healthcare devices.
  • Built-in Protection: Includes over-voltage, over-current, and short-circuit protections for safe operation.
  • Efficient Design: Optimized for high efficiency and minimal heat generation.
  • Ideal Use: Perfect for powering medical devices like diagnostic and monitoring equipment.

This medical-grade AC adapter is essential for healthcare professionals seeking safety and reliability in their power solutions.

• Power Range: 15~24W

• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, E:EU, K:UK, A: AU
• Output voltage available from 5~48 VDC

• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 60.5L x 39W x 34H(mm)
• Weight: 120g

Model NO. MAX OUTPUT POWER OUTPUT VOLTAGE MIN LOAD MAX LOAD LOAD REGULATION LINE REGULATION RIPPLE & NOISE
APM19UA 15W 5-8V 0A 3.0A ±5% ±1% 100mV
APM19UB 20W 9-13V 0A 2.0A ±5% ±1% 180mV
APM19UC 20W 14-19V 0A 1.42A ±5% ±1% 200mV
APM19UD 20W 20-27V 0A 1.0A ±5% ±1% 250mV
APM19UE 20W 28-35V 0A 0.71A ±5% ±1% 280mV
APM19UF 20W 36-48V 0A 0.55A ±5% ±1% 360mV
APM19UG 18W 5-8V 0A 3.0A ±5% ±1% 100mV
APM19UH 24W 9-13V 0A 2.0A ±5% ±1% 180mV
APM19UJ 24W 14-19V 0A 1.71A ±5% ±1% 200mV
APM19UK 24W 20-27V 0A 1.2A ±5% ±1% 250mV
APM19UL 24W 28-35V 0A 0.85A ±5% ±1% 280mV
APM19UM 24W 36-48V 0A 0.66A ±5% ±1% 360mV
NOTED:
1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
3 : Max. Power (W) = Vo x Io

UL 60601 Certified 12V 2A Medical Grade AC Adapter | 5V 24V Switching Power Supply with US Plug
