Specifications
Brand Name :
ANENpower
Model Number :
APM05U
Certification :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Place of Origin :
Shenzhen
MOQ :
500pcs
Price :
Please contact our Sales
Payment Terms :
50% deposit, 50% before dispatch
Supply Ability :
500,000.00pcs/month
Delivery Time :
18~25 working days after receiving the deposit
Packaging Details :
PE bag / White box / Custom made
Input :
100 ~ 240Vac, 50 / 60Hz
Power Range :
4.5 ~ 6W
Certificates :
UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
Application :
Breath detectors/testers, ECG, EEG, portable medical devices, medical tablets, digital blood pressure monitors, etc.
MTBF :
100,000 Calculated Hours
Caze Size :
53L x 41W x 30H (mm)
Description

UL FCC certified 6W Max 5V Medical AC Adapter 12V Switching Power Supply 9V Transformer

The APM05U series is a family of wall mount Medical AC adapters (wall adapters/wall warts) equipped with U.S plug that are designed to offer 6W continuous output power with a single output of either 5V, 12V, or 24V (coming with a universal input of 100~240 Vac).

APM05U are burn-in test conducted and offer class II operation, low leakage current, over load protection (OLP), crowbar mode over voltage protection (OVP), and 2 x MOPP (Means of Patient Protection) classification to ensure the safety of the patient, caregiver, and device to which the power supply is applied. The series owns comprehensive protection designs along with all-inclusive safety certifications and conforms to major international safety standards including IEC/EN 60601-1. All modules are fully compliant with the Level VI efficiency standard and RoHS directive.

APM05U switching power supplies are designed for medical applications and are ideal for breath detectors/testers, ECG, EEG, portable medical devices, medical tablets, digital blood pressure monitors, etc.

• Power Range: 4.5~6W

• Universal AC Input 100~240 VAC
• Frequency: 50~60Hz
• AC Plug type: U:USA, E:EU, K:UK, A: AU
• Output voltage available from 5~18 VDC

• 2 x MOPP Compliance, IEC/EN60601-1 Approval
• LPS Compliance
• Protections: Short circuit / Over voltage / Over current
• Energy Efficiency Level VI
• No Load Power Consumption ≤ 0.1W
• MTBF > 100,000 hours
• Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
• All models meet RoHS and WEEE
• Dimension(L x W x H): 53L x 41W x 30H (mm)
• Weight: 70g

Model NO. MAX OUTPUT POWER OUTPUT VOLTAGE MIN LOAD MAX LOAD LOAD REGULATION LINE REGULATION RIPPLE & NOISE
APM05UA 6W 5-18V 0A 1.2A ±5% ±1% 100mV
APM05UB 6W 9-12V 0A 0.66A ±5% ±1% 180mV
APM05UC 4.5W 9V 0A 0.5A ±5% ±1% 180mV
APM05UD 6W 9V 0A 0.67A ±5% ±1%

180mV
