24W KR Plug KC KCC Certified 12V 24V AC DC Adapter 36V Switching Power Supply with EN/IEC 62368/61558
24W KR Plug KC KCC Certified 12V 24V AC DC Adapter 36V Switching Power Supply with EN/IEC 62368/61558
24W KR Plug KC KCC Certified 12V 24V AC DC Adapter 36V Switching Power Supply with EN/IEC 62368/61558
24W KR Plug KC KCC Certified 12V 24V AC DC Adapter 36V Switching Power Supply with EN/IEC 62368/61558
Specifications
Brand Name :
ANENpower
Model Number :
APS24R
Certification :
UL/CUL, FCC, CE, GS, TUV, CB, RCM, SAA, PSE, KC, UKCA
Place of Origin :
Shenzhen
MOQ :
500pcs
Price :
Please contact our Sales
Payment Terms :
50% deposit, 50% before dispatch
Supply Ability :
500,000.00pcs/month
Delivery Time :
18~25 working days after receiving the deposit
Packaging Details :
PE bag / White box / Custom made
Input :
100 ~ 240V AC , 50 / 60Hz
Output Power :
24W Max
Output Range :
5 ~ 48V / 500mA ~ 3000mA
Safety Approvals :
UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA
Standard :
EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347
Warranty :
3~5 Years
AC Plug :
EU / US / UK / AU and Others for your selection
Application :
Consumer electronic devices · Telecommunication devices · Office facilities · Industrial equipments
Description

24W KR Plug KC KCC Certified 12V 24V AC DC Adapter 36V Switching Power Supply with EN/IEC 62368/61558

Power your devices confidently with our 24W KR Plug AC/DC Adapter, featuring KC and KCC certifications for South Korea. Available in 12V, 24V, and 36V output options, this adapter ensures both safety and efficiency, fully compliant with EN/IEC 62368 and EN/IEC 61558 standards for IT and industrial applications.

  • Multiple Voltage Options: Choose between 12V, 24V, and 36V to meet the power needs of a wide range of devices.
  • KC & KCC Certified: Fully compliant with South Korean KC and KCC safety regulations, ensuring reliable performance.
  • EN/IEC 62368 & 61558 Compliance: Adheres to international standards for both low-voltage devices and industrial equipment.
  • Efficient Switching Power Supply: Provides consistent power with high energy efficiency, reducing power consumption and heat generation.
  • KR Plug Design: Tailored specifically for South Korean outlets, ensuring a perfect fit for easy use.
  • Wide Application: Suitable for powering consumer electronics, industrial machinery, and LED lighting systems.

This KC/KCC-certified power adapter is the ideal solution for safe, reliable power in South Korea, delivering dependable performance across various applications.

Datasheet
Input: 100 to 240V AC , 50 / 60Hz
Output power: 24W max
Output Range: 5 ~ 48V / 500mA ~ 3000mA
Protection: Overload protection
Over voltage protection
Short circuit protection
Safety Approvals: UL, FCC, CB, GS, CE, PSE, SAA, RCM, UKCA
Standard: EN/IEC 62368, EN/IEC 61558, EN/IEC 60601, EN/IEC 61347
Efficiency: Compliant with the lastest U.S energy regulation EISA 2007/DOE(Level VI), EU ErP and CoC version 5
AC plug: EU / US / UK / AU and Others for your selection
Standard DC Connector: 5.5*2.5 / 5.5*2.1 /5.5*1.7 / 4.8*1.7 / 4.0*1.7 / 3.5*1.35 / 6.3*3.0 with pin inside
Operating Temperature Range: 0--40°C
Storage Temperature Range: -20 --- 85°C
High Humidity Operation: + 40 °C and 90 ~ 95% Humidity
Net weight: About 120g per unit
MTBF: 50,000 hours
Application: Consumer electronic devices · Telecommunication devices · Office facilities · Industrial equipments
Packing: PE bag + Carton or White Box + Carton or As your Request
