[main function] it is mainly used for base station signal transmission.
[main purpose] it is used in China Mobile, China Unicom, telecom, iron tower company and railway communication company.
[structural form] mainly steel pipe and angle steel structure.
[structure content] Q235B steel or Q345B steel or 20# steel is generally used, all of which are hot-dip galvanized for anti-corrosion treatment, and the connecting bolts are grade 6.8. The tower top is equipped with lightning rod, and the lightning protection grounding resistance is less than or equal to 10 ohms.
[technical parameters] wind speed resistance: 30m / s, ice wrapping resistance: 8mm, seismic intensity: 8 degrees, working temperature: 35-55 ℃, perpendicularity: 1 / 1000.
[height dimension] 10m-50m.
[product features] round steel or angle steel is used as the tower column material, with small wind load coefficient and strong wind resistance. The tower column is connected by external flange or angle steel clad iron, and the bolts are tensioned, which is not easy to be damaged and reduces the maintenance cost.
[service life] 50 years

Hebei Chang Tong Steel Structure Co., Ltd.
located in the hometown of China Tower, is a modern big-scale professional company fabricating triangular communicationtower,
four-corner communication tower, cable tower, single-tube tower, camouflage communication tower and transmission line
tower.integrating design,fabrication and marketing,annual production capacity reaches more than 30,000 tons.
Company always adhere to the business strategy of "survive by quality, develop by credit, increase efficiency by science and
technology", continuously carry out technical transformation,complete production equipment, reliable production process,
adopt advanced CNC angle steel production line, CNC sheet production line and various supporting equipment. The
equipment has a first-class iron tower stakeout center, all of which implement microcomputer lofting, which guarantees the
processing quality and provides a strong guarantee for production, which can fully meet the design and production requirements of various types of towers and substation structures.
Our steel tower products have won good reputation from our customers,including China tower,China mobile,China
unicom,China telecom,State grid and so on.In addition,our products also were exported to many countries and
areas,including South American,Africa,Southeast Asia and Ireland.
