240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings
240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings
240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings
240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings
Specifications
Brand Name :
MONTON
Model Number :
240/800 ECA/W33
Place of Origin :
CHINA
MOQ :
1
Price :
USD
Packaging Details :
Singlebox
Delivery Time :
7-35 days
Certification :
ISO9001
Payment Terms :
T/T
Supply Ability :
10000PCS/WEEK
Description

240/800 ECA/W33 Radial Spherical Bearing , Non - Standard Precision Ball Bearings

A spherical roller bearing is a rolling-element bearing that permits rotation with low friction, and permits angular misalignment. Typically these bearings support a rotating shaft in the bore of the inner ring that may be misaligned in respect to the outer ring. The misalignment is possible due to the spherical internal shape of the outer ring and spherical rollers.Despite what their name may imply, spherical roller bearings are not truly spherical in shape. The rolling elements of spherical roller bearings are mainly cylindrical in shape, but have a profile that makes them appear like cylinders that have been slightly over-inflated.

240/800 ECA/W33

d 800 mm
D 1150 mm
B 345 mm
d2 ≈ 910 mm
D1 ≈ 1028 mm
b 22.3 mm
K 12 mm
r1,2 min. 7.5 mm

da min. 828 mm
Da max. 1122 mm
ra max. 6 mm

240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings

Calculation data
Basic dynamic load rating C 13431 kN
Basic static load rating C0 28500 kN
Fatigue load limit Pu 1660 kN
Reference speed 220 r/min
Limiting speed 400 r/min
Calculation factor e 0.27
Calculation factor Y1 2.5
Calculation factor Y2 3.7
Calculation factor Y0 2.5
Mass
Mass bearing 1200 kg
240/800 ECA/W33 SKF Radial Spherical Bearing Non-Standard Precision Ball Bearings
