Specifications
Brand Name :
MONTON
Model Number :
30205
Place of Origin :
CHINA
MOQ :
1
Price :
USD
Packaging Details :
Singlebox
Delivery Time :
7-35 days
Certification :
ISO9001
Bearings :
30205
d :
25
D :
52
T :
16.25
Description

china 30205 bearing manufacturer

Product description

This 30205 25x52x16.25 taper wheel bearing supports high radial loads and axial loads in one direction between a rotating and non-rotating member. The tapered roller bearing is formed by combining a cone (inner ring assembly) and a cup (outer ring). It has a 7,800 revolutions per minute (RPM) limit with grease lubrication, and a 10,000 RPM limit with oil lubrication.

Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

30205

Ship Rudder Shafts Taper Roller Bearing / Sealed Tapered Roller Bearing
d 25 mm
D 52 mm
T 16.25 mm
d1 ≈ 38 mm
B 15 mm
C 13 mm
r1,2 min. 1 mm
r3,4 min. 1 mm
a 12.33 mm
Abutment dimensions
Ship Rudder Shafts Taper Roller Bearing / Sealed Tapered Roller Bearing
da max. 32 mm
db min. 31.5 mm
Da min. 44 mm
Da max. 46 mm
Db min. 48 mm
Ca min. 2 mm
Cb min. 3 mm
ra max. 1 mm
rb max. 1 mm
Calculation data
Basic dynamic load rating C 38.1 kN
Basic static load rating C0 33.5 kN
Fatigue load limit Pu 3.45 kN
Reference speed 11000 r/min
Limiting speed 13000 r/min
Calculation factor e 0.37
Calculation factor Y 1.6
Calculation factor Y0 0.9
Mass
Mass bearing 0.15 kg

Product features

  • Cone (inner ring assembly) and cup (outer ring) combine to form a complete single tapered roller bearing
  • Supports high radial loads and axial loads in one direction between a rotating and non-rotating member
  • RPM limit of 7,800 with grease lubrication and 10,000 with oil lubrication
