Totally enclosed housing slew drive High reliability For HCPV & PV

designed worm motor slewing drives PE3C/ZE3C with Hydraulic motor

Slewing Drive

By adopting slewing bearing as its core component,slewing drive can bear axial force, radial force and tilting moment simultaneously. Slewing drive is widely applied in modular trailers, all types of cranes, aerial working platform, solar tracking systems and wind power systems.

Electric and planetary gearboxes can be designed according to customer's requirment.Slewing drive has the advantage for saving space in facilities,max load capacity in a compact design,extensive lifespan, reduced maintenance costs.

Glossary

Tilting Moment Torque: Torque is the load multiplied by distance between the position of load and the center of slewing bearing. If the qorque generated by load and distance is greater than the rated tilting moment torque, slewing drive will be overturned.

Radial load: Load vertical to the axis of slewing bearing

Axial load: Load parallel to the axis of slewing bearing

Holding torque:It is the reverse torque.When the drive is rotating reversely, and parts are not damaged,The maximum torque achieved is called holding torque.

Self-locking: Only when loaded, the slewing drive is not able to reverse rotate and thus called self-locking.

Hourglass worm

Hourglass worm: Compare with traditional worm, hourglass worm can withstand a survivability load that is four to nine times greater.As the special hourglass shape of the drive allows more teeth to be engaged at one time,enabling much higher torque endurance.It can increase the durability, precision,and efficiency and maximum load capacity in a compact design.

--Customer can choose the motor according to our already designed slewing drive connect dimension.

--We can customized the connection dimension according to customer's motor connect dimension.

--We can help to provide the whole parts with Hydraulic motor, DC motor, AC motor, Stepper or Servo motor.

slew drive
slew drive applications
slew drive factory
slew drive for heavy duty vehicle
slew drive for solar pv tracking for aerial working platform
slew drive for solar tracker
slew drive for solar tracking and mobile cranes
slew drive for solar tracking and mobile cranes manufacturers
slew drive for solar tracking and mobile cranes suppliers
slew drive for solar tracking bracket factory
slew drive gearbox
slew drive manufacturers
slew drive motor
slew drive price
slew drive solar
slew drive solar tracker
slew drive sun tracker suppliers
slew drive used in the photovoltaic for aerial working platform
slew drive used in the photovoltaic for construction machinery
slew drives
slew drives solar
slew ring bearing
slewing drive
slewing drive for solar tracker

PE3C/ZE3C SLEWING DRIVE

Attached the below model for your selection:

Standard Model Slewing Drive:
A. Enclosed housing (SE Series)
B. Open Housing (S Series)
C. Special Type

Structure drawings


1, Housing base
2, Slewing Ring
3, Raceway
4, Seal
5, Top Plate
6, Drive(hydraulic motor /electronic motor )
7, Motor Adapter
8, O-ring
9, Input Hole
10, Shaft Opposite to Motor
11, End Cap
12, Cover
13, Encoder

Friendship Recommendation

• Vertical installation

It is advised to mount the slewing drives referring to attached drawing upside in solar applications for better protection.
For other applications, the mounting directions shall be based on the evaluation of the protection level and it shall be better for better protection.

• Horizontal installation

It is advised to mount the slewing drives upside down on the azimuth axis in solar applications for better protection and add protection for the elevation axis.
For other applications, the mounting directions shall be based on the evaluation of the protection level and it shall be better for better protection.
