CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
Specifications
Brand Name :
MONTON
Model Number :
CRBH5013AUUC1P5
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
USD
Payment Terms :
T/T
Supply Ability :
10000PCS/WEEK
Delivery Time :
7-35 days
Packaging Details :
Singlebox
Type :
Roller
Seals type :
Sealed
Material :
GCr15 bearing steel
Bore size :
30mm
Outside diameter :
55mm
Precision rating :
P5
Application :
swiveling tables of machining centers,main SPINDLE
Structure :
Other Structure
Number of row :
Single Row
Feature :
Cross Roller,Long Life,High Speed
Product name :
Crossed Roller Bearing,Hot sale China Wanda Crossed Cylindrical Roller Slewing Bearing
Cage :
Steel Cage.Brass Cage.Nylon Cage
Description

CRBH5013AUUC1P5 50*80*13mm crossed roller bearing

series harmonic reducer​

Shaft diameter Identification Main dimensions Mounting dimensions (mm) Basic dynamic load rating Basic static load rating weight
(mm)
inner ring outer diameter width Chamfer da Da C Co (Kg)
r (N) (N)
(mm) d D B (min)
50 CRBH5013A 50 80 13 0.6 56 74 17.3 20.9 0.29

IKO CRBH crossed roller bearing feature:

Crossed roller bearings are two-row cylindrical rollers that are vertically aligned with each other through a nylon spacer on a 90-degree V-shaped raceway. Therefore, the cross-roller bearing can withstand multiple loads such as radial load, axial load and moment load. . The size of the inner and outer rings is miniaturized, the extremely thin form is a small size close to the limit, and has high rigidity, and the DK crossed roller bearing accuracy can reach P2-P5.

CRBH series crossed roller bearing (Integrated Outer/Innner Ring,without Mounting Holes)

CRBH series crossed roller bearings: Due to the ultra-thin design and no mounting holes in the outer and inner rings, flanges and support bases are required for installation. In addition, because the outer ring and the inner ring are integral structures, installation has no effect on performance, so stable rotational accuracy and torque can be obtained. It is suitable for occasions where the outer ring and inner ring are rotated but the size is required to be reduced.

IKO CRBH crossed roller bearing application:

It is suitable for cases where the space is limited, where the high rigidity and hig rotation accuracy is required. Mainly used in engineering machinery, machine tools, automobiles, metallurgy, mining, petroleum, machinery, electric power, railways and other industries.

CRBH5013AUUC1P5 50*80*13mm crossed roller bearing series harmonic reducer
