H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
H7001C-2RZHQ1P4DBA High Precision Ceramic Angular Contact Bearings For Engraving Machine
Specifications
Brand Name :
MONTON
Model Number :
H7001C-2RZHQ1P4DBA
Place of Origin :
CHINA
MOQ :
1
Price :
USD
Supply Ability :
10000PCS/WEEK
Delivery Time :
7-35 days
Packaging Details :
Singlebox
Certification :
ISO9001
Payment Terms :
T/T
Description

H7001C-2RZHQ1P4DBA 10*28*8mm

high precision ceramic angular contact bearings for Engraving machine

Part Number H7001C-2RZHQ1P4DBA
Bearing Type Angular contact ball bearing
For Load Direction Combined Radial and Thrust
Construction One
Single Row/Double Row Single
Seal Type Open
Precision Rating P4 (ABEC-7) P5 (ABEC-5)
Contact Angle 15
Duplex DB (back-to-back arrangement)
DF (face-to-face arrangement)
DT (tandem arrangement)
Bore Dia (d) 12 mm
Bore Dia Tolerance -0.004mm to 0
Outer Dia (D) 28 mm
Outer Dia Tolerance -0.005mm to 0
Width (B) 8 mm
Width Tolerance -0.08mm to 0
Ring Material Gcr15
Ball Material SN24 Ceraimc Ball Si3N4
Cage Material TYN (ball guided polyamide resin cage)
TR (outer ring guided polyamide resin cage)
Dynamic Load Rating (Cr) (KN) 6.1
Static Load Rating (Cor) (KN) 2.9
Axial Load (KN) 2.4
Max Speed (Grease) (RPM) 57500
Max Speed (Oil) (RPM) 87500
Preload EL (extra light preload)
L (light preload)
M (medium preload)
H (heavy preload)
CP (special preload)
CA (special axial clearance)
Lubrication Required
Shaft Mount Type Press Fit
Temperature Range -40 to 120 ºC
Weight (grams) 0.021
H7001C-2RZHQ1P4DBB,H7001C-2RZHQ1P5DBA,H7001C-2RZHQ1P5DBB,H7001C-2RZHQ1P4SUL,H7001C-2RZHQ1P5SUL
