35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
35tac72b High precision spindle ball screw bearing Japan nsk
Specifications
Brand Name :
MONTON
Model Number :
35tac72b
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
USD
Payment Terms :
T/T
Supply Ability :
10000PCS/WEEK
Delivery Time :
7-35 days
Packaging Details :
Singlebox
Description

Axial angular contact ball bearings 35TAC72B
Bearing number : 35TAC72B

Size (mm) : 35x72x15

Brand : MONTON

Bore Diameter (mm) : 35

Outer Diameter (mm) : 72

Width (mm) : 15

Angle (α) - 60 °

d1 - 47 mm

d2 - 55 mm

r min. - 1 mm

r1 min. - 0,6 mm

D1 - 55 mm

D2 - 60,7 mm

Weight - 0,31 Kg

(Grease) Lubrication Speed - 3 600 r/min

(Oil) Lubrication Speed - 5 000 r/min

TAC B series bearings incorporate NSK’s recently developed molded polyamide resin cage. In addition, using extra-pure (EP) steel for the inner and outer rings has further enhanced service life. The axial rigidity is high because of a large number of balls and a contact angle of 60˚. Compared with tapered roller bearings of cylindrical roller bearings, this type has lower starting torque; so smoother rotation is possible
with less driving force.
