Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Laminar flow Fan filter Unit hood
Specifications
Description

ANLAITECH Brand HEPA filter Veritcal Class 100 Laminar flow fan filter Unit

The air through the primary filter press in static pressure box by centrifugal fan, after HEPA filter be filtered clean wind blowing out, clean air and indoor air continuously mixed and diluted to achieved purification effect.Laminar flow Fan filter Unit hood

Technical Parameters(HEPA FILTER INSIDE TYPE):

Model AL-LFU-2*2 AL-LFU-2*4 AL-LFU-3*4 FFU-4*4

Overall size

W * L * H (mm)

 600 * 600 * 450 600* 1200*450 915 * 1200 * 450 1200 * 1200 * 450

HEPA filter size

W * L * H (mm)

 440 * 440 * 69 440*1040*69 755 * 1040 * 69 1040 * 1040 * 69
Efficiency HEPA 0.3μm@≥99.99% OR ULPA 0.12@≥99.9995%
Prefilter (optional) Washable non-woven fabric
Construction Electro galvanized metal sheet OR stainless steel or high quality aluminum sheet
Air velocity (m/s) 0.35~0.45 0.35~0.45 0.35~0.45 0.35~0.45
Air flow (CMH) 410~513 840~1080 1290~1650 1720~2160
Speed control 3 modes, 5 modes, or induction control
Noise (dB) 48 ~ 50 48 ~ 52 50 ~ 56 52 ~ 58
Consumption AC ≤ 98 ≤ 150 ≤ 180 ≤200
DC ≤ 65 ≤ 90 ≤ 130 ≤160
Power AC single phase 110/220V OR three phase 220/380V 50/60Hz Or DC 220V
Overload protection Included (terminals or quick coupling are optional)
Weight (KG) 28 40 47 55

Laminar flow Fan filter Unit hood

Laminar flow Fan filter Unit hood

FEATURES:

1.Low consumption,super performance and low operation cost

2.Scientific air passage design, low resistance, low noise, save space

3.Flexible design to suit various needs

4.Safe and operation friendly

5.Muiti-level protective devices

Laminar flow Fan filter Unit hood

Laminar flow Fan filter Unit hood

Laminar flow Fan filter Unit hood

Our Services

Factory testing (all the sets you ordered):

All of equipment is individually factory tested for safety and performance in accordance with international Standards. Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.

Factory test include:

--appearance testing

--functional test and visual inspection

--electrical safety tests

--air velocity testing

--noise testing

Warranty:

Our equipment is warranty for 1 year excluding consumable parts and accessories.

All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.

Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.

Laminar flow Fan filter Unit hood

Laminar flow Fan filter Unit hoodAbout Us

Automatic production line.

Nearly 20 years experience in cleanroom industry.

We are an expert in providing customized solutions.

Timely delivery with perfect quality.

Fortune 500 companies’ choice.

Have passed ISO9001.2008 certification.

Laminar flow Fan filter Unit hoodLaminar flow Fan filter Unit hoodLaminar flow Fan filter Unit hoodLaminar flow Fan filter Unit hood
