1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India
1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India
Specifications
Place of Origin :
Shandong, China
Brand Name :
Katop
Certification :
CE, ISO9001
Model Number :
QTZ40-4808
Rated Lifting Moment :
400Kn.m
Rated Loading Capacity :
4T
Max. Lifting Load :
4T
Max. Lifting Height :
120M
Span :
48M
Application :
construction
Feature :
Tower Crane
the lifting speed: :
72/36 m/min(2 fall) / 17.5/35m/min(4 fall)
the slewing speed: :
0.73/0.37 m/min
the trolleying speed: :
39/26 m/min
the climbing speed: :
0.4 m/min
the free standing height: :
29m
the main chord: :
160*160*12(mm)
the mast section: :
1.5*1.5*2.2(m)
the color: :
any color you want
MOQ :
1 UNIT
Packaging Details :
Nude packed, well fixed, uninstalled
Delivery Time :
About 30-50workdays after receipt the deposit
Payment Terms :
30%TT in deposit, the balance 70%TT before shipment or by LC at sight
Supply Ability :
60units/month
Description

Specifications
1. Lifting height 29 m, loading capacity 4t, long jib length 40 m

2.Factory supply, low price

3.Installation support

4.Good after-sales service

Main Technical Parameters of QTZ40 (4808) Tower Crane

Item

Unit

Independent type

Attached type

Multiplying power

α=2

α=4

Rated lifting moment

KN.m

400

Max lifting weight

t

2

4

Max Working range

m

48

Min Working range

m

3

Lifting weight at max range

t

0.8

Telescoping speed

m/min

0.4

Range of max lifting weight

m

20.97

10.96

Lifting speed

m/min

72/36

17.5/35

Lifting height

m

29

120

60

Rotating speed

m/min

0.73/0.37

Motor total power

KW

25.82

luffing speed

m/min

39/26

counterweight

f

8.22

Whole machine dead weight

t

21.46 (exclusive of counterweight)

Independent height

1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India

A.The trolleying mechanism1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India

The trolleying mechanism specification

Trolley mechanism

Trolleying speed

Motor model

Power

Motor rotating speed

39/26 m/min

YEZS100L-4/6

2.2/1.5 Kw

1380(rpm)

B.The slewing mechanism1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India

The slewing mechanism specification

Slewing mechanism

Slewing speed

Motor model

Power

Motor rotating speed

0.73/0.37r/min

(QTH80.1)YZR132M

6-3.7Kw

960(rpm)

C.The lifting mechanism1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India

The lifting mechanism specification

Lifting speed

Fall

a=2

a=4

Loading capacity (t)

2

4

4

2

Lifting speed (m/s)

72

17.5

35

36

Motor model/power/motor rotation speed

YZTD200L-4/8/24

15/15/4 Kw

1385/680/195(rpm)

D.The jacking mechanism1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India

The jacking mechanism specification

Jacking mechanism

Jacking speed

Motor model

Power

Motor rotating speed

m/min

kw

r/min

Work pressure

Mpa

1. 4T new condition QTZ40 (4808) mini Single-gyration tower crane hot sale in India
