Specifications
Brand Name :
Realpark
Model Number :
RPL-XY9
Certification :
CE and ISCO9001
Place of Origin :
China
MOQ :
2
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/A, D/P
Supply Ability :
1000 set/Month
Delivery Time :
1-2 weeks
Packaging Details :
139*13*16cm/20kgs/Carton，141*23*28cm/30kgs/Wooden
Product Type :
LPR Parking Controller
Recognition Accuracy :
≥ 99%
LED Screen: :
LED module 64*32
Working humidity :
5%-85%
Working Temperature: :
-25℃~+70℃
Supported License Plate Formats :
European, Middle East, Southeast Asia, Africa, Chinese
Power Supply :
AC110 ~ 230V
Power consumption :
150W Max, AC 220V±10％/50Hz
Dimension :
230*290*1360mm
Weight :
20kg
Description

License Plate Recognition Parking Controller Up To 100.000 License Plate Capacity


Product Description:
The LPR Parking Controller is designed with a range of communication interfaces such as TCP/IP, RS485, and RS232 to provide seamless integration with other systems. With its versatile communication interfaces, the LPR Parking Controller can easily be integrated into parking management systems, access control systems, and other systems that require access control or monitoring.

The LPR Parking Controller is a type of License Plate Recognition (LPR) system that is designed to support a variety of license plate formats. It supports European, American, and Chinese license plate formats, making it ideal for use in different parts of the world. The LPR Parking Controller uses advanced algorithms to recognize license plates accurately and quickly, making it an efficient and reliable system for managing car parking systems.

The LPR Parking Controller is designed to work in different environments, with a working humidity range of 5%-85%. This makes it suitable for use in different weather conditions, including areas with high humidity levels. The LPR Parking Controller has a power consumption of 150W Max, and it operates on AC 220V±10％/50Hz.

Products Details Advantages:

License Plate Recognition Parking Controller Up To 100.000 License Plate Capacity

Product Specifications:

Products Model RPL-XY9
ALPR Camera CPU Specialized license plate recognition chip
Sensor 1/3" CMOS Image Sensor
Minimum illumination 0.01Lux
Lens 6mm fixed focus lens
Built-in light 4 high-power LED white lights
Plate recognition accuracy ≥98%
Triggering mode Video trigger, coil trigger
Image output

1080P(1920x1080),960P(1280x960),

720P(1280x720),D1(704x576),CIF(352x288)
Picture output 2 mega-pixel JPEG
Video compression format H.264 High Profile , Main Profile, Baseline , MJPEG
Network interface 10/100,RJ45
IO 2 input & 2 output 3.5mm connecting terminals
Serial interface 2 x RS485
Audio Interface 1 input & 1 output
SD Card Support SD2.0 standard Micro SD(TF) card with a maximum capacity of 32G
Power Supply AC220V
Power Consumption ≤7.5W
Working Temperature -25℃~+70℃
Main Component Parameters

LED Screen

X04 Control Board

 LED Screen Size 160mm*320mm(P4.75 2 colors LED 2 lines)
LED Screen Resolution LED module 64*32
Voice Temporary vehicles can be broadcast, the monthly car is welcome, and the journey is safe and other vehicle voice reminders
Display Support a variety of LED modules
Chip ARM Cortex-M Series RISC core core chip
Screen Control Supports standard horizontal and vertical screens, which can be switched by pressing the button;
Display Control Supports three-color, two-color, and multiple color displays (hardware and software vary);
ALPR Camera Type

Connect with mainstream cameras such as A/B/C and Dahua;

4. Provide SDK development kit and free technical guidance;

5. Provide a full range of docking solutions to support the Internet of Things, car wash systems, license plate recognition systems, and platform payment system debugging and matching.

The connection supports offline use, encryption, and personalized development;

6. Supports two-line and four-line display screens, equipped with traffic light interface;

7. Built-in voice broadcast system, the real voice is loud and clear;

8. Universal voice can be expanded to meet personalized needs.
Secondary Development

Provide SDK development kit and free technical guidance;

5. Provide a full range of docking solutions to support the Internet of Things, car wash systems, license plate recognition systems, and platform payment system debugging and matching.

The connection supports offline use, encryption, and personalized development;

6. Supports two-line and four-line display screens, equipped with traffic light interface;

7. Built-in voice broadcast system, the real voice is loud and clear;

8. Universal voice can be expanded to meet personalized needs.
Full Integrated Solution Provide a full range of docking solutions to support the Internet of Things, car wash systems, license plate recognition systems, and platform payment system debugging and matching. The connection supports offline use, encryption, and personalized development;
Screen Type Supports two-line and four-line display screens, equipped with traffic light interface;
Voice System Built-in voice broadcast system, the real voice is loud and clear;
Customization Universal voice can be expanded to meet personalized needs.
Power interface 12V mode, input 5A, output can be equipped with 2 modules, current >3.5A, built-in anti-reverse connection function
General Parameters Protection class IP42,Dustproof and Waterproof Function
Power Supply Meanwell LPS-150-12(12V 12.5A),159*97*30mm (L*W*H)
Working Temperature ‘-10℃～60℃(Optional thermostat)
Working humidity 5%-85%
Power consumption 150W Max, AC 220V±10％/50Hz
Device size 230*290*1360mm(Width*Thickness*Height)
Net Weight ≈20kgs(139*13*16cm, Carton Package)
Gross Weight ≈30kgs(141*23*28cm, Wooden Package)

This LPR Parking Controller is an essential component of an elevated car parking system, car parking management system, or car parking camera system.

License Plate Recognition Parking Controller Up To 100.000 License Plate Capacity


Applications of LPR Parking Controllers RPL-XY9:
LPR (License Plate Recognition) parking controllers are applications that utilize advanced technology to manage and monitor parking facilities efficiently. Here are some key applications and benefits of LPR parking controllers.

1. Automated Entry and Exit:

Vehicles can enter and exit parking areas without manual ticketing, as the system automatically scans and

recognizes license plates.

2. Access Control:
LPR systems can restrict access to certain areas based on license plate recognition, ensuring only

authorized vehicles can enter.


3. Real-Time Monitoring:
Operators can monitor parking space availability in real-time, allowing for better management of resources.

4. Payment Processing:
Integration with payment systems enables automatic billing based on the duration of stay,

simplifying the payment process for users.


5. Data Collection and Analytics:
Collects data on parking patterns, peak hours, and user behaviors, which can be analyzed for

improved operational strategies.

6. License Plate Database Management:
Maintains a database of recognized license plates for various purposes, including enforcement of

parking regulations or tracking frequent users.

7. Integration with Other Systems:
Can be integrated with city-wide traffic management systems or mobile applications for seamless user experiences.

8. Security Enhancements:
Helps improve security by tracking vehicles in real-time and identifying suspicious activity based on license plate data.

License Plate Recognition Parking Controller Up To 100.000 License Plate Capacity

Intelligent Parking Management System Installation Case Diagram

License Plate Recognition Parking Controller Up To 100.000 License Plate Capacity

FAQ:

Q1: What is a License Plate Recognition (LPR) camera system?
A license plate recognition camera system uses optical character recognition to read vehicle license plates. It is commonly used for access control, parking management, and law enforcement.

Q2: How does your LPR system work?
Our LPR system uses a high-resolution camera to capture vehicle license plate images, processes the images, and then uses advanced algorithms to extract and recognize license plate information.


Q3: What are the main features of your all-in-one LPR machine?
Our all-in-one machine includes real-time license plate recognition, access control, data logging, and integration with other security systems.


Q4: Is your LPR system suitable for outdoor use?
Yes, our LPR system is designed to withstand all kinds of weather conditions and is suitable for outdoor installation.


Q5: Can your system be integrated with existing security systems?
Of course! Our LPR system can be easily integrated with existing security and access control systems to enhance overall security.


Q6: What types of vehicles can your LPR system recognize?
Our system can recognize a variety of vehicles, including cars, trucks, and motorcycles, regardless of their license plate format.


Q7: How accurate is the license plate recognition?
Our LPR system has a recognition accuracy rate of over 97%, depending on environmental conditions and license plate visibility. The recognition accuracy rate in some countries exceeds 99.9%.


Q8: What kind of maintenance does the LPR system require?
Regular maintenance includes cleaning the camera, LED display, main control board of the all-in-one machine, updating software and checking system connections to ensure optimal performance.


Q9: What is the installation process of your LPR system?
Installation usually includes the license plate recognition all-in-one machine, connecting power and configuring software. Our team provides full support throughout the process.


Q10: What support options do you offer after purchase?
We provide technical support, software updates and maintenance services to ensure that your system runs smoothly.


Q11: Is there a subscription fee to use the LPR system?
Our LPR system has a one-time basic charge, and lifetime technical support and free upgrades are provided after it is sold out.


Q12: What happens if the system fails or malfunctions?
If a failure occurs, we have a professional support team that can troubleshoot and solve the problem as soon as possible.


Q13: How can I get a quote for your LPR system?
You can request a quote through our website or contact our sales team directly for personalized advice based on your specific needs.
