Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference
Specifications
Place of Origin :
China
Brand Name :
EagleX or can be customized
Certification :
CE, FCC
MOQ :
1pc
Delivery Time :
7days
Payment Terms :
LC,TT,CAD,Alipay
Supply Ability :
According to the project
Interference distance :
800-1500M
Battery :
7000mA
Power supply :
29.4V 2A
Main unit weight :
6Kg
Packaging weight :
72 × 30 × 15 (main unit 7.5 + fan 7.5) cm
Description

Long-Range, Efficient Cooling Fan 1.5KM Jamming Distance 8-Channel Portable Anti-Drone Jammer Gun Wideband Interference

Equipment operating frequency (frequency can be customized according to needs)

Output Port Operating Frequency Average Output Power Channel Output Power
433M 433MHz 40dBm 20dBm/30KHz(min)
900M 860-930MHz 40dBm 20dBm/30KHz(min)
1.2G 1160-1220MHz 40dBm 20dBm/30KHz(min)
1.4G 1400-1450MHz 40dBm 20dBm/30KHz(min)
1.5G 1150-1620MHz 44±1dBm 20dBm/30KHz(min)
2.4G 2400-2500MHz 44±1dBm 20dBm/30KHz(min)
5.2G 5150-5350MHz 44±1dBm 20dBm/30KHz(min)
5.8G 5725-5850MHz 44±1dBm 20dBm/30KHz(min)

8 Interference frequency band:

433M, 900M, 1.2G, 1.4G, 1.5G, 2.4G, 5.2G, 5.8G

Long Range 1.5KM 8 Channel Portable Anti Drone Jammer Gun Wideband Interference

EXLY8 product advantages and features

  • 1. EXLY8 adopts ultra-high frequency broadband seamless interference technology.
  • 2. Single-channel switch technology controls power output.
  • 3. High effective power (channel power) and long interference distance.
  • 4. Effective segmentation, only interferes with drone control and video transmission frequency, and will not interfere with other frequencies.
  • 5. Adopts built-in battery (plug-in design, battery is removable), with continuous battery life of more than 30 minutes.
  • 6. Two external high-power fans for better heat dissipation.
  • 7. Imported devices and slow start circuit design can avoid the sparking phenomenon caused by mechanical switches, with high integration and stable operation.

Radio interference related technologies

Wireless communication must ensure sufficient carrier-to-interference ratio (signal-to-noise ratio) to effectively receive and complete communication. The communication signal jammer destroys the drone reception conditions by generating interference signals with the same frequency as the drone reception, cuts off the communication connection between the drone and the remote control transmission, and achieves the effect of interfering with communication.
The interference power is certain, and the shielding radius of the unobstructed space is determined by the path attenuation and the control remote control transmission signal level.


Distance and attenuation comparison table:

Distance (m) 900MHz Attenuation (dB) 1575MHz Attenuation (dB) Distance (m) 2400MHz Attenuation (dB) 5800MHz Attenuation (dB)
1 38 44 25 66 72
2 44 50 30 67.5 73.5
3 48 54 35 69 75
4 50 56 40 70 76
5 52 58 45 71 77
6 53.5 59.5 50 72 78
7 55 61 60 73.5 79.5
8 56 62 70 75 81
9 57 63 80 76 82
10 58 64 90 77 83
15 61.5 67.5 100 78 84
20 64 70 200 84 90
