Specifications
Brand Name :
QEEPO
Model Number :
QP-ES
Certification :
CE/ISO
Place of Origin :
SHANGHAI
MOQ :
1 set
Price :
150USD
Payment Terms :
T/T
Supply Ability :
500 SET PER month
Delivery Time :
5-8 working days
Packaging Details :
carton box
name :
ionizer bar static eliminator
POWER :
≤25W
application :
Folding machine
Working voltage :
MAX 7Kv AC
operation mode :
Power frequency AC
features :
manufacturer;OEM
length :
80~4000mm
product :
static eliminator
Description

Folding machine ionizer bar static eliminator for Objects fall from the folding machine

The laundry folding machine is used to handle such items as sheets, towels and tablecloths. At present, such articles are usually made of artificial fibers, and a large amount of static electricity will be generated when such articles are transported through narrow conveyor systems and folding stations. Under the action of static electricity, such articles will be adsorbed on the conveyor belt. As a result, they cannot reach the folding station, and then they are either automatically ejected from the machine or wound around the rollers. Replacing the standard canvas belt with a conductive belt does not solve this problem. Qp-es electrostatic eliminator can solve this problem

TYPE QP-ES
Working voltage MAX 7Kv AC
Working current MAX 5mA
working frequency 50/60Hz
operation mode Power frequency AC
Working distance 3~30cm
Working humidity 0 ~ 70% RH (no freezing, no condensation)
Recommended installation distance 3~5cm
Discharge electrode spacing 25mm
Discharge electrode material SS. / W
POWER ≤25W
Section size 20.5*36.5mm
working temperature 0~50℃
Temperature (23 ± 3) ℃; Humidity (50 ± 5)%; Test voltage ± 1kV ~ ± 100V;Test distance: 50mm

7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall

Material upgrading, safe insulation, high insulation composite materials are adopted externally, no metallization structure design is adopted, internal structure is upgraded, safety is doubled, internal coupling current limiting structure is adopted, ion release capacity is increased, electrostatic removal speed is fast, various technologies are adopted, innovative structure design is adopted, ion generation is greatly increased, installation is simple and convenient, and high insulation fixed slider is adopted for fixed installation.

7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall7Kv AC Ionizer Static Eliminator Bar For Folding Machine Objects Fall

Shanghai qipu electrostatic technology co., LTD is located in D5 NO.508 Dongye Road Dongjing Songjiang Shanghai, is a set of static control equipment & corona treatment machine research and development, manufacturing, sales and service in one of the high-tech enterprises. The product of the company's main research and development is: electrostatic eliminator bar,corona treater, ion air bar, high voltage generator, ionizing air blower,static field meter ,static sensor,Electrostatic electret equipment and so on.

FAQs

Q: Are you trading company or manufacturer?
A: Yes, we are factory, all machine is made by ourselves and we can provide customize service according to your requirement. We have production line, R&D department, QC department, sales and after-sales service department and so on.
Q: How long is your delivery time?
A: Generally, it is 1-3 day if the goods are in stock. And it is about 3 to 7 days if the goods are not in stock, it depends on your quantity requirement.
Q: Is this machine easy to use and if we have no experience to use it, can we operate it well?
A: Yes, our machine is intended to designed easier operation for you. We can provide machine videos or pictures to you; it can help us how to operate it well.
