24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
Specifications
Brand Name :
YUESHUN
Model Number :
YD19-10-R
Certification :
CE RoHS
Place of Origin :
Wenzhou, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T to our company account or by paypal
Supply Ability :
5000Pcs/Day
Delivery Time :
3-7 work days
Packaging Details :
The product is packed in foam box to prevent damage during transportation.
Pulse Time :
Less than or equal to 50ms
Item :
Piezo Touch Switch
Max. Current :
100mA
Max. Voltage :
24VDC
Operation type :
Momentary
Operating Temperature :
-20℃～+55℃
Description

Aluminum Body Red Shell No-lamp Piezo Touch Switch 50MS Pulse Time for 19mm Mounting Panel

Feature

- Red galvanized housing, aluminum alloy, 19mm Mounting Hole.

- The piezoelectric switch Terminal has two wires, one “+” and one “-”.Conventional wires are 30 cm long and can be customized to other lengths.

- The color of the shell of the switch is galvanized, which can be red, yellow, green, blue, black, green, etc., or customized according to customer's requirements.Pure color, good gloss, not easy to fade.

- This Piezo switch is widely used in Petroleum Dispensing, Mining Equipment, Access Control and so on.

Product .Specification

Model Number

YD19-10-R

Mounting Hole

19mm

Max.Switch Rating

Ith : 100mA Ui : 24V DC

Body Material

Aluminum

Body Color

Red

The Front Shape

Flat Round Head

Terminal Type

0.22 Square wire (wire length can be customized)

Switch Operation

Momentary

Pulse Time

Less than or equal to 50ms

Mounting panel thickness

1-8 mm

Protection Grade

IP68 IEC529

Working Humidity

10%-90%

Operating Temp

-40℃～+70℃

Working Pressure

3~8N

Operating life:

More than 500,000 cycles

Size

24VDC Self Locking 19mm Latching Push Button Switch Galvanized Housing
