Blue Shell Piezo Push Button Switch Touch On / Off With CE RoHS Certication
Blue Shell Piezo Push Button Switch Touch On / Off With CE RoHS Certication
Blue Shell Piezo Push Button Switch Touch On / Off With CE RoHS Certication
Blue Shell Piezo Push Button Switch Touch On / Off With CE RoHS Certication
Specifications
Brand Name :
YUESHUN
Model Number :
YD19-10-Blue
Certification :
CE RoHS
Place of Origin :
Wenzhou, China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T to our company account or by paypal
Supply Ability :
5000Pcs/Day
Delivery Time :
3-7 work days
Packaging Details :
The product is packed in foam box to prevent damage during transportation.
Pulse Time :
Less than or equal to 50ms
Item :
Piezo Touch Switch
Max. Current :
100mA
Max. Voltage :
24VDC
Protection Level :
IP68 IEC529
Operating life :
More than 500,000 cycles
Description

19mm Blue Shell Piezo Touch Switch Aluminum Body IP68 50MS Pulse Time Touch on/off switches

FAQ

1. What is a piezoelectric switch and how does it work?

- When you touch the top button, the button generates a pulse for 50 milliseconds, and then the pulse disappears, no matter how long you touch it.Of course when you let go and touch again, repeat the above pulse

2. How long is the wire at the Terminal of the product?

- The length of our regular connecting wire is about 30, if you need longer or shorter, we can also customize it for you.

Product .Specification

Model Number

YD19-10-BLUE

Mounting Hole

19mm

Max.Switch Rating

Ith : 100mA Ui : 24V DC

Body Material

Aluminum

Body Color

Blue

The Front Shape

Flat Round Head

Terminal Type

0.22 Square wire (wire length can be customized)

Switch Operation

Momentary

Pulse Time

Less than or equal to 50ms

Mounting panel thickness

1-8 mm

Protection Grade

IP68 IEC529

Working Humidity

10%-90%

Operating Temp

-40℃～+70℃

Working Pressure

3~8N

Operating life:

More than 500,000 cycles

Size

Blue Shell Piezo Push Button Switch Touch On / Off With CE RoHS Certication
