Electric bike electric scooter electric balance car intelligent shared DC charging pile

USER MANUAL

用户手册

www.aokpower.cn www.ioaspow.com Mail:aokpower@126.com

Product name:Smart charging Pile for electric bicycle

产品名称:电动自行车智能充电桩

Model:iAD1400C-4L

产品型号:iAD1400C-4L

Networking mode: single or multi-machine networking

组网方式:单机或者多机联网

Communication method: 4G

通讯方式:4G

Payment method: QR code payment

支付方式:二维码支付

Applicable battery type: lead acid battery, lithium battery, iron battery

适用电池类型:铅酸电池,锂电池,铁电池

Input:AC 180V-264V～ 4A 50Hz

输入:AC 180V-264V～ 4A 50Hz

Output Voltage:22-88V DC(Automatic identification of battery type, battery voltage)

输出电压:22-88V DC(自动识别电池类型,电池电压)

Output Current:0.1-4.1A

输出电流:0.1-4.1A

Number of loads groups:4

输出负载数:4组

Connector pin definition:

1,Before using the device, please read the following instructions carefully:

1,在使用该设备之前,请仔细阅读以下说明:

• Please save this instruction for future reference.

1)请保存此指示以备将来参考.

• When installing this equipment, it should be placed on a reliable surface to avoid damage to the equipment due to dropping or impact.

2)在安装该设备时,应将其放置在可靠的表面上,以避免由于掉落或冲击而损坏设备.

• The operating environment temperature of this equipment must not exceed 40°C, otherwise it will be damaged.

3)本设备的运行环境温度不得超过40℃,否则会损坏.

• This equipment must be installed according to specifications.

4)该设备必须按规格安装.

• Before connecting the device to the power supply, please confirm whether the power supply matches the input power of the device.

5)在将设备连接到电源之前,请确认电源是否与设备的输入功率匹配.

• Do not place anything on the power cord of the device and avoid walking on it.

6)不要将任何东西放在设备的电源线上,避免在其上行走.

• Note all warning slogans on this device.

7)在该设备上注明所有警告口号.

• If the device is not used for a long time, please disconnect the device and put it in a dry environment.

8) 如果设备长时间不使用,请断开设备并将其置于干燥环境中.

• Do not pour any liquid on the device to prevent water splashing, water droplets, fire, or electric shock.

9)不要在装置上倒任何液体以防止水溅,水滴,火灾或电击.

• For safety reasons, this equipment cannot be arbitrarily dismantled. Only professional skilled personnel can disassemble the equipment.

10)出于安全原因,不能随意拆卸该设备.只有专业技术人员才能拆卸设备.

• This equipment is suitable for safe use at an altitude of 2000 meters and below.

11)该设备适用于海拔2000米以下的安全使用.

2,If one of the following situations occurs, please notify the special staff to deal with it:

2,如有下列情形之一,请通知专职人员处理:

1)The device has been immersed or has flowed into the liquid.

1)该装置已浸没或流入液体中.

2)The power cable insulation damage, plug damage.

2)电力电缆绝缘损坏,插头损坏.

3)The device is working abnormally.

3)装置工作异常.

4)The device has been dropped or hit and damaged.

4)设备已掉落,撞击或损坏.

5)The device has obvious damage.

5)装置损坏明显.

3, wiring diagram (with illustration)

3,整机图(附图)
