120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
Specifications
Use :
Other Trailers
Max Payload :
120 Tons
Size :
12500-17000*3000*1500 (mm) (L*W*H)
Place of Origin :
CHINA
Brand Name :
AOTONG
Rated Load :
80-120 Tons
Tyre Specifications :
10.00R20 / 11.00R20
No. Of the Tires :
8/12/16/20
Axle :
13 Tons Fuwa / BPW
Suspension :
Mechanical / Air suspension
King Pin :
2" & 3.5" exchangeable king pin
Brake Air Chamber :
Double chambers
Ladder :
Mechanical/Hydraulic ladder
Usage :
heavy object transport
Color :
Customer's request
MOQ :
1 UNIT
Price :
$18,900.00/sets >=5 sets
Certification :
ISO,CCC
Packaging Details :
Exporting Standard
Delivery Time :
25 days
Payment Terms :
TT
Description
WELCOME TO JUYUAN
Product Description
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation

Parameters of same type product

120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation

Product Details parameters (customizable)

1.Loading surface is low,loading time is saved and driving safety factor is high 2.Equipped with air suspension, the driving process is smooth 3.The whole vehicle adopts special accessories for export, and the export is unimpeded.
Model Number
LAT9200TDP-LAT9500TDP
Product
2/3/4/5 axles heavy duty low bed semi trailer (HOT SALE)
Color
Any color available as client’s need
Rated Load
80-120 Tons
Tare Weight
8-12 Tons
Tyre Specifications
10.00R20 / 11.00R20
No. Of the Tires
8/12/16/20
Axle
13 Tons Fuwa / BPW
No. Of the Axles
2/3/4/5
Leaf-spring
10
Suspension
Leaf spring / Air suspension
Outside Dimensions
12500-17000*3000*1500 (mm) (L*W*H)

Main Beam Material
Q345B manganese plates, automatic submerged arc welded
Upper:20mm, Lower:20mm, Mid web:12mm
The height of beam:500mm, “I” type beam
Brake Air Chamber
Double chambers
Floor
Steel sheet 4mm thickness or diamond plate
King Pin
2 & 3.5 exchangeable king pin
Landing Gear
28000 kg
Spare Wheel Carrier
One set of spare wheel carrier
Accessory
One tooling box with a set of standard trailer tool
Electrical System
24V, 7core socket, lights according to European standards.

Reference drawing

120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
Detail Presentation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
Materials & Process

We have perennial cooperation suppliers of raw materials with really good quality and have certain amount reserve, saving cost and production cycle, and make the product standardization. Constantly updated product design, technology is guaranteed.

120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation

Shandong Juyuan Automobile Technology Co., Ltd., is a professional manufacturer of varies types of semi trailers established in 1992 with well-equipped testing facilities and strong technical force. With advanced and proven technique in design, exploitation and production, our products with the brand "Aotong" are widely sold to countries all over the world with good reputation, enjoying high popularity in America, the Middle East, Africa, Southeast Asia and Russia, specially get good feedback from Kenya, Tunisia, Saudi Arabia, the Philippines, Myanmar, Vietnam, Thailand, Bangladesh, Tanzania, mozambique, Congo, Nigeria, Russia, etc. . Now we provide more than 60 types of trailers and also our trailers can be customized according to your specifications and design drawings. You are warm welcome to contact us and we are ready for you!!!

120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
120 Tons Max Payload Drop Deck Lowboy Truck Trailers for Heavy Duty Transportation
Packing & Delivery

The small and medium semi trailers with the size and numbers which can be put into the containers, usually use the container transport, to ensure the semi trailers will not scratch or lost during long-distance transit and saving transport cost. Large size semi trailer, use the truck head drag to the pier, if multiple trailers stacked, we’ll using rope to tied and fixed in the form of bulk maritime transport.
