Specifications
Use :
Truck Trailer
Type :
Semi-Trailer
Material :
Steel
Size :
13000*3000*1100 (mm)
Max Payload :
60000KG
Place of Origin :
CHINA
Brand Name :
AOTONG
Main beam :
Heavy duty I beam.
Side beam :
250mm I beam
Plate :
4mm checked plate
Ladder :
Mechanical spring ladder or hydraulic ladder
Axles :
3 * 13ton capacity
Suspension :
Mechanical suspension
Leaf spring :
10pcs
Tire :
12R22.5 / 11.00R20
Rim :
9.00-22.5 / 11.00R20
Kin pin :
2''/3.5'' bolt type
Price :
$15,800.00/pieces 1-4 pieces
Certification :
ISO,CCC
Packaging Details :
Exporting Standard
MOQ :
1 UNIT
Delivery Time :
25 days
Payment Terms :
TT
Description
Product Description
Customize the semi trailer according to your requirements.Professional semi trailer manufacturer with more than 20 years of production experience serve for you —AOTONG
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Brand
AOTONG
Name
3 axles lowbed semi trailer
Dimensions
13000*3000*1290(MM)
Platform
4mm checked plate
Rated Load
60000 kg
Tare Weight
9000 kg
Material of the Main Beam
Q345B manganese plates,
automatic submerged arc welded,height:500mm
Thickness:
Upper plate:18mm
Middle plate:12mm
Lower plate:20mm
Side beam
25# channel steel
Kin pin
50mm/90mm (bolt in type)
Landing gear
Single-side operation
Axles
13ton * 3 pieces
Suspension
Mechanical suspension, 10 pieces leaf spring
Braking system
Dual line braking system
6 Brake Chamber Double chambers
Tires Specifications
12R22.5 12pcs
Rims
9.0-22.5 12pcs
Electrical System
24 Volt, 7-way socket, LED light
Accessories
Spare Wheel Carrier 1 pieces, without tires
Tool Box
1 piece with a set of tools
Ladder
Mechanical ladder at rear side
Painting
Sand blasting
One time Primer coating
Two times finish coating
Wax sprayed before shipment
Color
Any color will be available
AOTONG low loader trailer can satisfy the concentrated force, the anti bump and the distortion resistance.Our lowbed semi trailer can meet load requirements on different kind of roads and has a long service life.
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
We start from every detail, carefully craft to customize your high-quality semi trailer.
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Excellent design ability
We have many experienced designers, according to your needs to develop the most reasonable design and meet your customized needs.
Click for your own design！
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Popular Colors and High Quality Painting
We use high quality paint to make our products beautiful, seamless, dustproof and easy to clean.KTL electrophoresis + powder
spraying, instead of traditional paint process to make a good bond with a solid base, good wear resistance, durability and has
good anti-corrosion effect and long paint life.
Which color do you want to customize, click to get more!
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Related Products
We also have rich production experience in the following models.
If this item is not what you like, then we suggest these items：
Click to get the models that have been shipped to your country！
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
2 axles lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
3 axles lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
4 axles lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Multi axles lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Extendable lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Detachable gooseneck semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Modular trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Multi line axle lowbed semi trailer
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
lowbed semi trailer with side wall
Our lowbed semi trailer ladder has a rib design to increase its load carrying capacity.
A variety of ladder can be selected, ordinary ladder, spring ladder, hydraulic ladder, hydraulic folding ladder. The spring ladder can be lowered by its own weight. Hydraulic ladder reduces labor strength. Folding the ladder will lower the up and down slope.
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Hydraulic Ladder 4 Axle Lowboy Trailer with 80 Ton 100 Ton Capacity and Durable Design
Packing&Shipping
In nude,Polish with water wax before shipment
1. By 40ft/45ft/40fr container
2. By bulk /roro ship
3. As your requirments.
Professional package saves freight cost for you. In order to prevent seawater corrosion,we will carefully Wrap film or covered tarpaulin.When goods arrive in Africa, Australia and even South America, they can maintain a good appearance.
High quality painting and professional transportation ensure good condition of goods.
We believe that we can win-win by providing detailed services.
