Brand | Aotong |
Rated Capacity | 35000kgs /Row @ 0.6Km/h |
Tare Weight | 3100 kgs/Row |
Material | S690, AH60, 40Cr high tensile Steel |
Loading Deck Height | 1175±300mm |
Width of Platform | 2990mm-3000mm |
Max Steering Angle | +/-55° |
Brake | Dual line pneumatic brake system,T30/30+T30 air chamber; parking brake; |
Electrical System | 24V, 7core socket, lights according to European standards. |
Wheelbase | 1500mm |
Tire | 215/75R17.5 |
Rim | 6.00-17.5 (10holes) |
Approaching Angle | 25°/ 28° |
Suspension | Hydraulic Air suspension with lifting and steering / Axle Steering |
Tire & Rims No /line | 8 sets |
Connection Platform | Optional by Cargo / Machine Size |
Pin Height | According to the height of the tractor saddle. |
Painting | Three coats painting; Any color will be available |
Welding | automatic submerged arc welded |
Lights | Rear light, rear reflector, turn indicative light, side |
reflector, fog lamp, number plate light | |
Painting | Three coats painting; Any color will be available |
Tool Box | One tool box with a set of standard trailer tools |
Tyre Carrier | One piece |
Electrical | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) Euro Standard |
Exw-factory | Wax -spray |
Color and Logo | Depends on the buyer’s requirement. |
Product Production | New Made and Stock Optional |
Tool Box | 1 box of standard tools |
Spare tire carrier | 2 sets |
