Specifications
Use :
Other Trailers
Max Payload :
40T
Size :
40KL
Place of Origin :
CHINA
Brand Name :
AOTONG
manhole :
2
material :
aolly
OE NO. :
Fuel tank trailer
Packaging Details :
In nude,Polish with water wax before shipment
1 By 40ft/45ft/40fr container
2 By bulk /roro ship
3 As your requirments.
Professional package saves freight cost for customers
Guarantee the firmness and safety of the goods
Port :
Tianjin/ Lianyungang/Qingdao/Shanhai port
Supply Ability :
1000 Unit/Units per Month
Price :
$19,200.00/units 1-2 units
Certification :
ISO,CCC
MOQ :
1 UNIT
Delivery Time :
25 days
Payment Terms :
TT
Description

3 Axles 35-50cbm Aluminum Fuel tank trailer

compartment 1,2,3,5 aviable
tyre tubless or tube tire



Discription:
1. Model: LAT9400GYY(Volume &Tank shape Optional )
2. Well welded tanker body
3. More than 15 years professional manufacturer experience
4. Be designed according to your requirements
5. CCC ISO9001 agreement
6. Small order can be accepted
7.12 month quality guarantee term
8. We accept 100% inspection, welcome to our factory at any time

Specifications:
-1. High transport efficiency, ensuring the products will not be deteriorated in the process of transportation, saving the packing materials to reduce the transport costs
-2. Equipped with gasification bed, intake control system, and thrusting control system to ensure the pipelines unimpeded.
-3. The tanks bulbar and the horizontal sextant angle are greater than the material rest angle, ensuring the discharging speed.
Product specifications:

45000L Three Axle Aluminum tank barrel Semi-Trailer
TANK BARREL Aluminium alloy 5083 Main beams high tensile steel Q345B
Curb Weight 6500kgs Payload 31000kgs
Total Weight 37200kgs Volume 42000 LITRES plus max 5% ullage.
Dimension OverallLength 12000 mm
Overall Width 2500mm
Overall Height 3800mm

A,TANK BARREL
1.Tank Material Aluminium alloy 5083
2.Main beams high tensile steel Q345B
a) Dish end 7.00mm conforming to ADR
b) Tand body 6.00mm conforming to ADR
c) Baffle 6.00mm conforming to ADR
2.Shell Finish Tank barrel outer surface cleaned out, paint. according to customer's
requirement.
3. Tank Profile

 Maximum profile design that maximizes volumetric capacity whilst
achieving a low centre of gravity.
4.Design Code/ Vapor Testing Hydrostatic test on each compartment.
5. Compartments 1 compartment
6.Bulkhead End Plate / dish end 7mm Aluminium alloy 5083 O dished bulkhead.
Dish end plate to be made by intact-plate without joint/connection.
7. Main Beam Standard features of a full-length aluminum alloy main frame
8..Roll Over Coaming / spill box Extrusion aluminium alloy in inverted 'U' section with full length
sliding rail for anti-fall protection system.

B. TANK FITTINGS AND PIPING
1.Manholes API standard 2nos, 20inch manhole with internal breath vent, overfill holes and
vapour transfer vent hole,
2.vapor recovery system API standard
3.Emergency Valve
API standard		 1nos, 3" , pneumatic controlled emergency valve at all compartments.
4.Piping

 4" alum discharge pipe to the left hand side of trailer with minimum
number of bends.Piping to be hydro-statically tested. The piping
slope toward front at angle of 2°(minimum 1.5°)
5.Loading Discharge Faucet 1nos, dust cap on the kerb. API standard
6. Accessories

 1nos, rotary product indicator mounted on API adaptor.
API Compartment number and capacity indicator for each
compartment to be installed near discharge faucets.
Compartment capacity to be decaled on rollover coaming beside
each compartment(both sides)
7.Control System

 1) Emergency valve control.
2) Emergency cut off with three cut off switches, one at front left
hand side, one at rear right hand side of trailer and one at right
hand side of trailer at compartment
8.Overfill Prevention

 2nos, 5 wire optic probe installed to manhole cover and 1no.
Optic socket,



Tank details:


Fuel tank trailer loading and delivery as below:


Company Information:

Qingdao Juyuan International Trading Co., Ltd. is an industry & trade company, with a factory, Liangshan Juyuan Special Vehicle Manufacturing Co., Ltd.

With advanced and proven technique in design, exploitation and production, our products with the brand "Aotong" are enjoying high popularity in America, the Middle East, Africa, Southeast Asia and Russia,specially get good feed back from Kenya,Tunisia,Saudi Arabia, the Philippines, Myanmar, Vietnam, Thailand, Bangladesh, Tanzania, mozambique, Congo, Nigeria, Russia, Singapre,South Korea etc. .
Now we provide more than 60 types of trailers. Our production can be done according to your requirements.

DEALING PROCESS
1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.

Export Market Distribution:


Market
Total Revenue (%)
Main Country

The Middle East
22.8
UAE,Bahrain,Iran,Iraq,Israel,Jordan,Kuwait,Lebanon,Oman Qatar,
Saudi Arabia,Syria,Yemen,Egypt

Southeast Asia
21.5
Vietnam, Philippines,Laos, Kampuchea, Thailand, Burma,
Malaysia, Singapore, Indonesia, Brunei, East Timor.

Central Asia
5.5
Kazakhstan, Uzbekistan, Kyrgyzstan, Turkmenistan, Tajikistan

Other Asia country
5.4
South Korea,India,Pakistan,Turkey

South America
8.8
Brazil, Bolivia, Uruguay, Peru, Chile, Argentina, Dominica, Cuba,
and so on.

Europe
7.8
Russia,Belarus and so on.

Africa
27.4
Congo, Tanzania, Ethiopia, Djibouti, Kenya, Angola, Chad,
Egypt, Sudan, Libya, Tunisia, Algeria, Sudan, Egypt, Libya,
Eritrea, Uganda, Rwanda,Burundi and the Seychelles.
Mauritania, Western Sahara, Senegal, Gambia, Mali,
Burkina Faso, Guinea, Guinea-Bissau, Cape Verde,
Sierra Leone,Liberia, Côte d'Ivoire, Ghana, Togo, Benin,
Niger, Nigeria and the Canary Islands. Cameroon, Equatorial
Guinea, Gabon and Zambia, Angola,Zimbabwe,
Malawi, Mozambique, Botswana, Namibia, and so on.

North America
0.8
Canada ,America,Mexico


Certificates and Successful case:

Your questions,we will anwser:

1. Can i have samples of this type of trailer to test the quality?


Yes, you can buy any samples to test the quality,our MOQ is 1 set.


2. What's the delivery time and can you lower the price?

It depends on your order. The delivery time is within 15 workdays after we received your prepayment. If you have place an order of large quantities, then ,of course, the price can be lowered.

3. Can i customize the painting and the trailer design?

Yes, we offer customized design and logo for reasonable type.

4. What's the payment method?

TT 30% as Deposit, Balance Before shipment by TT or L/C at sight

5.How do you ensure its quality?
We are direct factory and we have professional quality inspector.We will not let any imperfections departure from our factory.
