Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Specifications
Condition :
New
Steering :
Left
Horsepower :
351 - 450hp
Emission Standard :
Euro 2
Segement :
Heavy truck
Market Segement :
Logistics transportation
Engine Brand :
WEICHAI
Fuel Type :
Diesel
Engine Capacity :
> 8L
Cylinders :
10
Transmission Type :
Manual
Forward Shift Number :
10
Reverse Shift Number :
2
Maximum Torque(Nm) :
≤500Nm
Size :
6800x2496x2958
Gross Vehicle Weight :
6800 kg
Drive Wheel :
6x4
Passengers :
2
Seat Rows :
Single row
Rear Camera :
360°
ABS(Antilock Braking System) :
Yes
ESC(Electronic Stability Control System) :
Yes
Touch Screen :
Yes
Multimedia System :
Yes
Window :
Automatic
Air Conditioner :
Automatic
After-sales Service Provided :
Onsite Installation, Video technical support, Overseas Call Centers, Online support
Engine :
WD615.47
Tire :
295/80R 22.5 315/80R 22.5 12.00R20
Driving type :
6*4
Transmission :
HW19710
Cabin :
HW76 Comfortable Cabin
Price :
$36,500.00/units 1-2 units
Description
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Truck Model
ZZ4257S3241
Driving Style
Left/Right Hand Driving
Dimension(Lx W xH)(unloaded)(mm)
6800x2496x2958
Approaching angle/Departure angle(°)
16/70
Overhang(front/rear) (mm)
1500/725
Wheel base (mm)
3225+1350
Front track/ Rear track(mm)
2022/1830/1830mm
Max speed(km/h)
101
Curb weight(kg)
9180
Loading Weight(kg)
25000
Engine Model
Model WD615.47, water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
Engine Fuel type
Diesel
Engine Horse Power, max(kw/rpm)
371HP
Engine Emission
EURO II
Fuel tanker capacity (L)
400L
Clutch
Φ430 pull-type diaphragm spring clutch
Transmission Model
HW19710, 10 forwards and 2 reverse
Brake system-Service brake
Dual circuit compressed air brake
Brake system-Parking brake
spring energy, compressed air operating on rear wheels
Brake system-Auxiliary brake
Engine exhaust brake
Steering system
Model ZF8098 hydraulic steering with power assistance
Front axle
HF9, 9 tons loading capacity
Rear axle
HC16, 16 tons loading capacity
Color
optional
Tire
1200R20, 10+1pcs
Electrical system-Battery
2X12V/165Ah
Electrical system-Alternator
28V-1500kw
Electrical system-Starter
7.5Kw/24V
Cab
HW76 cab one sleeper, with air-condition,4 point full-floating air suspension, adjustable steering wheel with various heights and
angles, air suspension seat,etc.
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Rich Experience 6x4 Tractor Truck with WD615.47 Engine and 2 Reverse Shift Numbers
Q1: Can I buy a sample of this trailer to test the quality?
A1: Yes, you could buy one and test the trailer, our MOQ is 1 sets.

Q2: What is the date of delivery?
A2: The time of delivery is within 30 working days after we receive your advance payment. For mass production, it may takes 40~45 days.

Q3: Can you supply some easy worn spare parts?
A3: Yes, we can provide you with some easy worn spare parts at the factory price, such as traction pin, balance beam and ,
suspension parts, turntable, trailer brake pads, brake discs, bearings, etc..

Q4: What are the terms of payment?
A4: T / T 30% as deposit, before shipment by wire transfer or by L / C payable at sight.

Q5: Do you have used trailers or trucks for sale?
A5: We have some trailers or trucks for stock selection but brand new, from 2010-2017, price in discount.

Q6: Is it all right to make customer's own brand name?
A6: Yes, we accept OEM business.

Q7: Are you a manufactuer or trading company?
A7: We are a manufacturer, factory located in Liangshan,Shandong Province of China, welcome to visit us at any time.

Q8: Can you do the design for us?
A8: We have experienced engineer to make design for you according to your requirement and local road regulation.

Q9: Where is your loading port?
A9: Any China main port is acceptable, mostly we use Lianyungang port, Tianjin port.

Q10: Does your product have warranty service?
A10: We provide one year warranty period of the tank body, running gear and tank fittings.
