Automatic Armature Balancing Machine
Automatic Armature Balancing Machine
Automatic Armature Balancing Machine
Automatic Armature Balancing Machine
Specifications
Place of Origin :
China
Brand Name :
Nide
Certification :
None
Model Number :
ND-XSR-5BL-IIIC
MOQ :
1 set
Price :
Negotiable
Packaging Details :
Wooden case suitable for sea transportation
Delivery Time :
60 working days
Payment Terms :
T/T, L/C
Description

Automatic Armature Balancing Machine

Quick Detail:

1. Armature diameter range 40~56mm
2. It is suitable for automatic production line.
3. This machine has 5 working stations.
4. Qualified residual unbalancing value can reach 3gmm.
5. Rejected armature will be transfered to the specific conveyor automatically.
6. This machine does balancing by adding weight.

Description:

This machine does balancing by adding weight. There are 5 working stations, high efficiency and precision.This kind of 5 stations armature balancing machine is equipped with conveyor, can achieve automatic loading and unloading, balancing and cutting. Rejected armature will be transfered to the specific conveyor automatically. It is suitable for automatic production line.

Working station explaination:
1st station: loading&unloading---2nd station: preliminary measuring---3rd station: first time weight removing----4th station: second time weight removing---5th station: re-measuring

Technical parameter:

Armature lamination length

30~60mm

Armature diameter range

40~56mm

Balancing speed

1500~2200RPM

Cutting method

V shape

Pitch time

If initial unbalance value is less than 30gmm:28s/pc. Qualified residual unbalancing value can reach 3gmm.

Power

380V

Air supply

0.4~0.6MPa

Machine dimension

2000*1700*1800mm

Machine weight

4.5KW

Operation method

1500Kg

Competitive advantages:

It is suitable for automatic production line. Rejected armature will be transfered to the specific conveyor automatically.
