Electrical Motor Coil Inserting Machine , Stator Semi auto insertion machine

Quick Detail:

1. This can wind coil and insert wedge simultaneously.
2. Wedge fedding mode can be set according to different motor.
3. easy operation and convenient tooling change.
4. It is controlled by PLC. All the parameter can be set in the touch screen

Description:

This machine is used to inserting coil and wedge into stator. And it can insert coil and wedge simultaneously. This HMI can set all the necessary data. With easy and convenient tooling change process, this machine is suitable for three phase motor, fan motor and other motor, with a veriety model number but low output.

Wedge fedding mode can be set according to different motor.Horizontal Winding Inserting Machine is equipped with human-machine control interface, It has the characteristic of widely application, high automation, easy operation and convenient tooling change.

Specification:

Stator ID 20~110mm
Stator OD ≤160mm
Stator height 20~150mm
Tooling travel 60mm
Wire Material Copper wire/Alum wire
Slot number range 8-48 slots
Power supply 380V/ 50/60Hz 3Kw
Weight 400Kg
Dimension 1500*680*1500mm

Operation step:

Power on the machine

Insert the wire by winding form

Adjust the tooling according to different model stator

Put stator to the tooling

Set the stator diameter in the touch screen then select the pre-set data.

Press "start" button.

Machine will automatically do coil inserting.

Take out the stator

Application:

This machine is suitable for three phase motor, fan motor and other motor, with a veriety model number but low output.

Information needed for stator winding inserting machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Wire connection drawing
4. Stator application
5 Required productivity
6 Other technical requirement

The touch screen of this machine
