Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable
Specifications
Brand Name :
Qingying or QY
Model Number :
LC/UPC 4F Outdoor Fiber Optic Cable
Certification :
ISO 9001 2015
Place of Origin :
Dongguan China
MOQ :
1 pcs
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
2000 Meter/Meters per Week
Delivery Time :
7-15 days after deposit
Packaging Details :
Package : 2KM to 4KM Per Reel.,Export Carton Packing or customized
Product name :
DLC/UPC 4F Outdoor Fiber Optic Cable
Application :
video transmiting & broadcast vehicles trailers
Fiber count: :
1~12 Cores
Color: :
Black or Yellow
Package : :
2KM to 4KM Per Reel.
Application: :
Outdoor Communication Equipment
Fiber Type: :
Simplex or Duplex
Description

Armored Fiber Optic Cable Single Mode/ 4F Outdoor Multimode / Outdoor Fiber Optic Cable

A FTTA patch cord is used as: 3G 4G base station, Aerospace & Defence, Equipment diagnosis,

FO sensor, FTTA ,FTTP, FTTX,WIMAX, BBU, RRU, RRH, LTE.Multimode DLC/PC DLC/PC Outdoor

Optical Cable Assembly GYFJH 2A1a(LSZH) 7.0mm 2 Cores with protected branch.

ITEM
PARAMETER
Connector type
LC/UPC, SC/UPC, FC/UPC, ST/UPC. Optional
Fiber mode
Multi-mode
Operating wavelength
850, 1300nm
Test wavelength
850, 1300nm
Insertion Loss
<=0.2db
Return Loss
>=35db
Repeatability
<=0.1
Interchangeability
<=0.2dB
Durability
<=0.2dB
Fiber Length
1m, 2m….. any length optional.
Length and tolerance
10cm
Operating Temperature
-40C ~ +85C
Storage Temperature
-40C ~ +85C

Technical Data

Item Single mode Multi mode
Splicing Type UPC APC PC
Insertion Loss <or=0.3dB <or=0.2dB <or=0.3dB
Reture Loss >or=45dB >or=55dB >or=35dB
Repeatability <or=0.1dB <or=0.1dB <or=0.1dB
Temperature -40/+80

Specifications & Performances

Cable
Count		 ITEM CABLE
OD.mm(a)		 S.S.T.
OD.mm(b)		 T.B.O.F.
OD.mm(C)
4F 4.5MM Φ4.5±0.2 Φ2.4±0.02 Φ0.5
6F 4.5MM Φ4.5±0.2 Φ2.6±0.03 Φ0.5
8F 5.0MM Φ5.0±0.2 Φ2.8±0.05 Φ0.5
10F 5.0MM Φ5.0±0.25 Φ3.0±0.05 Φ0.5
12F 5.5MM Φ5.5±0.25 Φ3.2±0.05 Φ0.5
24F 7.0MM Φ7.0±0.3 Φ4.3±0.05 Φ0.5

Application:


3G 4G base station, Aerospace & Defence, Equipment diagnosis,

FO sensor, FTTA ,FTTP, FTTX,WIMAX, BBU, RRU, RRH, LTE.Multimode DLC/PC DLC/PC Outdoor Optical

Cable Assembly GYFJH 2A1a(LSZH) 7.0mm 2 Cores with protected branch.
