Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
Specifications
Brand Name :
Huanghe
Model Number :
PVC Insulated Electrical Cable
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
200
Payment Terms :
TT/Western Union /LC
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Conductor Core :
Annealed Copper or Hard Drawn Aluminum
Insulation :
Polyvinyl Chloride (PVC) Insulated
Outer Sheath :
Polyvinyl Chloride (PVC) Sheathed
Armor :
DSTA/SWA/AWA Armored or Unarmored
Rated Voltage :
0.6/1KV
Cross Section Area :
0.75mm2-1000mm2
Standard :
IEC60502, BS IEC ASTM DIN, GB/T12706, VDE, UL
Color :
Black or Customized
Application :
Construction, Industrial, Underground, Power Station
Feature :
Abrasion-resistant
Description

Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores

PVC Insulated Cable Rated Voltage:

0.6/1kv

Number of cores of PVC Insulated Cable:

1 core, 2 core, 3 core, 3+1 core, 3+2 core, 4 core, 4+1 core, 5 core

PVC Insulated Cable Application:

PVC insulated cables is mainly applied to fixed installation for rated voltage 0.6/1kv of power transmission and distribution line. It is usually installed in ground, within facilities, in cable canals, in concrete, in conditions where heavier mechanical loads and specially tensile strains. Used in electric power plants, transformer stations, industrial plants, metropolitan networks and in other electric plants, same as for connection of signalling devices in industry, traffic and similar.

PVC Insulated Cable Usage Characreristics:

1) The long-term working tempeture of cable should be not higher than 70 degree.
2) When core is in short-circuit (Max. 5s), the tempeture should not exceed 160 degree.
3) While installation the ambient tempeture should not be lower than o degree, and bending radius should not be less than 10 times of outer diameter.

Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores

PVC Insulated Cable Types:

PVC Insulated Cable TypesDescriptionCoresNomi Section Area
Cu/PVC/PVCcopper core, pvc insulated,
pvc sheathed, electric cable		1 core
2 core
3 core
4 core
5 core
3+1 core
3+2 core
4+1 core		1.5~1000mm2
Al/PVC/PVCaluminum core, pvc insulated,
pvc sheathed, electric cable
Cu/PVC/STA/PVCcopper core, pvc insulated, steel tape armoured, pvc sheathed, electric cable4~1000mm2
Al/PVC/STA/PVCaluminum core, pvc insulated, steel tape armoured, pvc sheathed, electric cable
Cu/PVC/SWA/PVCcopper core, pvc insulated, steel wire armoured, pvc sheathed, electric cable
Al/PVC/SWA/PVCaluminum core, pvc insulated, steel wire armoured, pvc sheathed, electric cable
ZR-Cu/PVC/PVCcopper core, pvc insulated, pvc sheathed, flame retardant, electric cable1.5~1000mm2
ZR-Al/PVC/PVCaluminum core, pvc insulated, pvc sheathed, flame retardant, electric cable
ZR-Cu/PVC/STA/PVCcopper core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable4~1000mm2
ZR-Al/PVC/STA/PVCaluminum core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable
ZR-Cu/PVC/SWA/PVCcopper core, pvc insulated, steel wire armoured, pvc sheathed,
flame retardant, electric cable
ZR-Al/PVC/SWA/PVCaluminum core, pvc insulated, steel wire armoured, pvc sheathed, flame retardant, electric cable


Construction PVC Insulated Aluminium Wire Abrasion Resistant 1 Core - 5 Cores
