XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
Specifications
Brand Name :
Huanghe
Model Number :
Direct Burial Aluminum Cable
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
200 Meters
Price :
0.1-200 USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Conductor :
Solid Aluminum Copper
Insulation :
XLPE/PVC/PE
Armour :
DSTA/SWA/AWA Or Unarmoured
Sheath :
PVC/PE
Color :
Black
Application :
Construction
Design Standard :
IEC 60502
Description

XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard

Applications

These cables are used for electricity supply in low voltage installation system, They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants, where there is no risk of mechanical damage. The lead sheath brings an enhanced resistance to aromatic hydrocarbons.

0.6/1kV PVC or XLPE Insulated Electrical Aluminum Cable

Aluminum Cable Types

Description

Cores

Nomi Section Area (mm2)

Al/PVC/PVC

aluminum core, pvc insulated, pvc sheathed, electrical cable

1 core

2 core

3 core

4 core

5 core

3+1 core

3+2 core

4+1 core

1.5, 2.5,

4, 6,

10, 25,

35, 50,

70, 95,

120, 150,

185, 240,

300, 400, 500, 630, 800, 1000

Al/PVC/STA/PVC

aluminum core, pvc insulated, steel tape armoured, pvc sheathed, electrical cable

Al/PVC/SWA/PVC

aluminum core, pvc insulated, steel wire armoured, pvc sheathed, electrical cable

Al/XLPE/PVC

aluminum core, xlpe insulated, pvc sheathed, electrical cable

Al/XLPE/STA/PVC

aluminum core, xlpe insulated, steel tape armoured, pvc sheathed, electrical cable

AlXLPE/SWA/PVC

aluminum core, xlpe insulated, steel wire armoured, pvc sheathed, electrical cable

0.6/1kV Flame Retardant & Fire Proof Electrical Aluminum Cable

Aluminum Cable Types

Description

Cores

Nomi Section Area (mm2)

ZR- Al/PVC/PVC

aluminum core, pvc insulated, pvc sheathed, flame retardant, electrical cable

1 core

2 core

3 core

4 core

5 core

3+1 core

3+2 core

4+1 core

1.5, 2.5,

4, 6,

10, 25,

35, 50,

70, 95,

120, 150,

185, 240,

300, 400, 500, 630, 800, 1000

ZR- Al/PVC/STA/PVC

aluminum core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electrical cable

ZR- Al/PVC/SWA/PVC

aluminum core, pvc insulated, steel wire armoured, pvc sheathed, flame retardant, electrical cable

NH- Al/PVC/STA/PVC

aluminum core, pvc insulated, steel wire armoured, pvc sheathed, fire proof, electrical cable

Medium Voltage XLPE Insulated Electrical Aluminum Cable

Aluminum Cable Types

Description

Cores

Nomi Section Area (mm2)

Al/XLPE/PVC

aluminum core, xlpe insulated, pvc sheathed, electrical cable

1 core

3 core

25, 35,

50, 70,

95, 120,

150, 185,

240, 300,

400, 500, 630, 800, 1000

Al/XLPE/STA/PVC

aluminum core, xlpe insulated, steel tape armoured, pvc sheathed, electrical cable

Al/XLPE/SWA/PVC

aluminum core, xlpe insulated, steel wire armoured, pvc sheathed, electrical cable

XLPE PVC PE Direct Burial Aluminum Electrical Wire With IEC 60502 Standard
