3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable
Specifications
Brand Name :
Huanghe
Model Number :
XLPE Insulated Copper Cable
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
200
Payment Terms :
TT/Western Union /LC
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Conductor :
Annealed Copper
Insulation Material :
Cross Linked Polyethylene (XLPE)
Outer Sheath Material :
Polyvinyl Chloride (PVC) or Polyethylene (PE)
Armoured :
DSTA/SWA/AWA Armored or Unarmored
Voltage :
600V to 35KV
Cross Section Area :
0.75mm2-1000mm2
Number of Cores :
1 core to 5 cores
Standards :
IEC60502, BS IEC ASTM DIN, GB/T12706, VDE, UL
Colour :
Black or Customized
Application :
Construction, Industrial, Underground, Power Station
Feature :
Abrasion-resistant
Fire Performance of Cable Sheaths :
Cables can be supplied with special flame retardant PVC outer sheath to comply with the flame test requirements.
Packing :
Drum, Optional
Description

3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable

XLPE Insulated Copper Cable Rated Voltage:

0.6/1KV, 3.6/6KV, 6/10KV, 8.7/15KV, 12/20KV, 18/20KV, 21/35KV, 26/35KV

XLPE Insulated Copper Cable Number of cores:

1 core, 2 core, 3 core, 3+1 core, 3+2 core, 4 core, 4+1 core, 5 core

XLPE Insulated Copper Cable Introduction:

XLPE insulated electrical cable is a kind of cable suitable for distribution network and other fields. It has simple structure, light weight, good heat resistance, strong load capacity, no melting, chemical corrosion resistance, high mechanical strength.

XLPE insulated electrical cable have higher long-term working temperature and greater current rating, and under the condition of the same environment, XLPE cable may be reduced size (normal cross section) 1 or 2 class in comparison with PVC cable. These are not only improving the quality and properties of products, but also reduce cables' production cost.

3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable

XLPE Insulated Copper Cable Technology Property:

1. Bending dadius:
Bending radius of single core cable is 20 (d+D) ±5%
Bending radius of multi-core cable is 15 (d+D) ±5%.
D=Aetual outer diameter of cable sample (mm)
d=Aetual diameter of the comductor (mm)


2. Installation temperature:
It should be heated where ambient temperature is below 0°C


3. Lever difference of cable installation:
Not restricted by the difference of level along the route.

3 Core Cross Linked Polyethylene Wire Annealed Copper Xlpe Armoured Cable


XLPE Insulated Cable Types:

0.6/1kV XLPE Insulated Electric Cable
XLPE Cable Types Description Cores Nomi Section Area (mm2)
Cu/XLPE/PVC copper core, xlpe insulated, pvc sheathed, electric cable

1 core

2 core

3 core

4 core

5 core

3+1 core

3+2 core

4+1 core

1.5, 2.5,

4, 6,

10, 25,

35, 50,

70, 95,

120, 150,

185, 240,

300, 400, 500, 630, 800, 1000
Al/XLPE/ PVC aluminum core, xlpe insulated, pvc sheathed, electric cable
Cu/XLPE/STA/PVC copper core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable
Al/XLPE/STA/PVC aluminum core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable
Cu/XLPE/SWA/PVC copper core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable
Al/XLPE/SWA/PVC aluminum core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable

Medium Voltage XLPE Insulated Electric Cable
XLPE Cable Types Description Cores Nomi Section Area (mm2)
Cu/XLPE/PVC copper core, xlpe insulated, pvc sheathed, electric cable

1 core

3 core

25, 35,

50, 70,

95, 120,

150, 185,

240, 300,

400, 500, 630, 800, 1000
Al/XLPE/ PVC aluminum core, xlpe insulated, pvc sheathed, electric cable
Cu/XLPE/STA/PVC copper core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable
Al/XLPE/STA/PVC aluminum core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable
Cu/XLPE/SWA/PVC copper core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable
Al/XLPE/SWA/PVC aluminum core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable


1KV 3 Core XLPE Insulated Cable (Uarmoured) Technical Data:

No.cores x
cross-sec.		 Insulation
thickness		 Sheath
thickness
Nominal
value		 Outer Ø
approx.		 weight
approx.		 Current ratings in air 30℃ Current ratings buried 20℃ maximum DC resistance at 20℃
mm2 mm mm mm kg/km A A Ω/km
3x1.5 0.7 1.8 10.1 132 21 28 12.1
3x2.5 0.7 1.8 11.0 171 28 37 7.41
3x4.0 0.7 1.8 12.0 225 37 48 4.61
3x6.0 0.7 1.8 13.1 296 47 61 3.08
3x10 0.7 1.8 15.3 440 64 82 1.83
3x16 0.7 1.8 17.5 638 85 107 1.15
3x25 0.9 1.8 21.0 954 115 138 0.73
3x35 0.9 1.8 23.1 1266 140 165 0.52
3x50 1.0 1.8 23.4 1614 168 198 0.39
3x70 1.1 1.9 27.4 2264 213 242 0.27
3x95 1.1 2.0 30.6 2975 263 290 0.19
3x120 1.2 2.1 34.0 3776 307 330 0.15
3x150 1.4 2.3 38.6 4682 357 371 0.12
3x185 1.6 2.4 43.3 5802 415 418 0.10
3x240 1.7 2.6 48.1 7437 498 485 0.08
3x300 1.8 2.8 52.2 9313 575 548 0.06
