Cu XLPE STA PVC XLPE Copper Cable 1kv Low Voltage Armored Cable IEC60502
Cu XLPE STA PVC XLPE Copper Cable 1kv Low Voltage Armored Cable IEC60502
Cu XLPE STA PVC XLPE Copper Cable 1kv Low Voltage Armored Cable IEC60502
Cu XLPE STA PVC XLPE Copper Cable 1kv Low Voltage Armored Cable IEC60502
Specifications
Brand Name :
Huanghe
Model Number :
XLPE Insulated Copper Cable
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
200
Payment Terms :
TT/Western Union /LC
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Conductor Core :
Copper
Insulation Material :
Cross Linked Polyethylene (XLPE) PVC
Outer Sheath Material :
XLPE PVCＰＥ
Armoured Type :
armoured
Cross Section Area :
１ｍｍ２to 1000mm2
Standards :
IEC60502,
Colour :
Customized　ｂｌａｃｋ　
Application :
Construction, Power Station
Description

Cu XLPE STA PVC XLPE Copper Cable 1kv Low Voltage Armored Cable IEC60502

CU/XLPE/STA/PVC 0.6/1kv

CV-STA, Power Cable, 0.6/1 Kv, 1/C, Cu/XLPE/PVC/SWA/PVC (IEC 60502-1)
0.6/1 kV XLPE Insulated and Double Sheathed Power Cable with Steel Tape Armor
Application
For use in ducts, trays and direct burial in ground. The cable is subject to immerse in water all the time.
Construction
Conductor: Solid or stranded copper
Insulation: Cross-linked polyethylene
Inner Sheath: Polyvinyl chloride (Black)
Armor:Steel Tape
Core-covering: Binding tape
Outer Sheath: Polyvinyl chloride (Black)
Standard
IEC 60502-1.
Installation
CV-STA cable can be installed in duct, tray or direct burial. It is recommended that the installation instructions indicated by the Local Electric Code, or any equivalent, be followed, so that the safeguarding of persons and the integrity of the product will not be affected by deficiencies in the installation.


Cu/XLPE/STA/PVC Copper xlpe armored cable 1kv low voltage cable

Type
Discription
Rated Voltage (KV)
No. of cores
Nominal Cross-sectional Area (mm2)
Cu
Al
VV/YJV
VLV/YJLV
VV/YJV: Copper conductor PVC/XLPE insulated and PVC sheathed powercables.
VLV/YJLV: Aluminium conductor PVC insulated and PVC sheathed power cables.
0.6/1KV
1
1.5~1200
2.5~1200
2
1.5~300
2.5~300
3
1.5~300
2.5~300
4
1.5~300
2.5~300
5
1.5~300
2.5~300
3+1
1.5~300
2.5~300
3+2
1.5~300
2.5~300
4+1
1.5~300
2.5~300
VV22 / YJV22
VLV22 / YJLV22
VV22/YJV22 : Copper conductor PVC insulated and PVC sheathed steel tap armoured power cables.
VV22/YJV22 : Aluminium conductor PVC insulated and PVC sheathed steel tap armoured power cables.
0.6/1KV
1
10~500
10~500
2
1.5~300
2.5~300
3
1.5~300
2.5~300
4
1.5~300
2.5~300
5
1.5~300
2.5~300
3+1
1.5~300
2.5~300
3+2
1.5~300
2.5~300
4+1
1.5~300
2.5~300
VV32 / YJV32
VLV32 / YJLV32
VV32/YJV32 : Copper conductor PVC insulated and PVC sheathed steel wire armoured power cables.
VLV32/YJV32 : Aluminium conductor PVC insulated and PVC sheathed steel wire armoured power cables.
0.6/1KV
1
50~500
50~500
2
35~300
50~185
3
25~300
35~300
4
25~300
35~300
5
25~240
35~240
3+1
25~300
35~300
3+2
25~300
35~300
4+1
25~240
35~240



Cu/XLPE/STA/PVC Copper xlpe armored cable 1kv low voltage cable
