Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape
Specifications
Brand Name :
Huanghe
Model Number :
YJV32 VV32 YJV22 VV22 YJV62 VV62
Certification :
ISO OHSAS CCC IEC
Place of Origin :
China
MOQ :
200
Price :
0.1-100
Payment Terms :
TT/Western Union /LC
Supply Ability :
50000meters per week
Delivery Time :
5-8days
Packaging Details :
wooden drum
Application :
Telecommunication, Outdoor, Networking, telecom, CCTV
Color :
black, Customized, or as per client requst, White
Jacket :
PVC, PE LSZH PVC, PE, Black Polyethylene (PE), LSOH
Product name :
Black Bare Copper Armored UTP FTP SFTP Outdoor D-Link Cat6 Cable, armored1000ft extension cable, GYXTW Outdoor Cable, cat5e cable, GYTA fiber cable
Conductor material :
Copper or Aluminum
Insulation material :
XLPE
Description

Low Voltage Armoured Electrical Cable STA SWA AWA Polyvinyl Chloride PP Tape

Type: Armoured Electric Cable

Rated Voltage: 0.6/1kV~26/35kV

Conductor: Hard drawn aluminum or annealed copper

Insulation: XLPE or PVC

Filler: Polypropylene tape (pp tape)

Wrap Tape: Non-woven fabric or PP wrapping tape

Armour: Steel tape armoured or steel wire armoured or aluminum wire armoured

Outer Sheath: Polyvinyl chloride (PVC)

Standards: CCC/UL/CE Certificate

0.6/1kV PVC Insulated Armoured Electric Cable
PVC Armoured Cable Types Description Cores Nomi Section Area (mm2)
Cu/PVC/STA/PVC copper core, pvc insulated, steel tape armoured, pvc sheathed, electric cable 1 core2 core3 core4 core5 core3+1 core3+2 core4+1 core 1.5, 2.5,4, 6,10, 25,35, 50,70, 95,120, 150,185, 240,300, 400
Al/PVC/STA/PVC aluminum core, pvc insulated, steel tape armoured, pvc sheathed, electric cable
Cu/PVC/SWA/PVC copper core, pvc insulated, steel wire armoured, pvc sheathed, electric cable
Al/PVC/STA/PVC aluminum core, pvc insulated, steel wire armoured, pvc sheathed, electric cable

0.6/1kV XLPE Insulated Armoured Electric Cable
XLPE Armoured Cable Types Description Cores Nomi Section Area (mm2)
Cu/XLPE/STA/PVC copper core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable 1 core2 core3 core4 core5 core3+1 core3+2 core4+1 core 1.5, 2.5,4, 6,10, 25,35, 50,70, 95,120, 150,185, 240,300, 400
Al/XLPE/STA/PVC aluminum core, xlpe insulated, steel tape armoured, pvc sheathed, electric cable
Cu/XLPE/SWA/PVC copper core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable
Al/XLPE/STA/PVC aluminum core, xlpe insulated, steel wire armoured, pvc sheathed, electric cable

0.6/1kV Flame Retardant & Fire Proof Armoured Electric Cable

FRLS Armoured Cable Types

Description

Cores

Nomi Section Area (mm2)

ZR- Cu/PVC/STA/PVC

copper core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable

1 core

2 core

3 core

4 core

5 core

3+1 core

3+2 core

4+1 core

1.5, 2.5,

4, 6,

10, 25,

35, 50,

70, 95,

120, 150,

185, 240,

300, 400

ZR- Al/PVC/STA/PVC

aluminum core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable

ZR- Cu/PVC/SWA/PVC

copper core, pvc insulated, steel wire armoured, pvc sheathed, flame retardant, electric cable

ZR- Al/PVC/SWA/PVC

aluminum core, pvc insulated, steel wire armoured, pvc sheathed, flame retardant, electric cable

NH- Cu/PVC/STA/PVC

copper core, pvc insulated, steel wire armoured, pvc sheathed, fire proof, electric cable
