Single Core Armour PVC Insulated Cable With BS 5467 IEC60502 Standard
Single Core Armour PVC Insulated Cable With BS 5467 IEC60502 Standard
Single Core Armour PVC Insulated Cable With BS 5467 IEC60502 Standard
Single Core Armour PVC Insulated Cable With BS 5467 IEC60502 Standard
Specifications
Brand Name :
Huanghe
Model Number :
VV
Certification :
ISO OHSAS CCC
Place of Origin :
China
MOQ :
200
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000 meter per week
Delivery Time :
5-8 days
Packaging Details :
Wooden drum
Jacket :
PVC Or Rubber,PVC or PE
Conductor material :
Copper,Aluminum,aluminum alloy 1350-H19
Color :
Black or other
Conductor :
Copper Core,Stranded
Standard :
IEC60502
Packing :
Drum,optional
Description

Single Core Armour PVC Insulated Cable With BS 5467 IEC60502 Standard

Construction of PVC insulated cable

1. Cores :1 .2 .3 .4 .5 3+1 .4+1 cores

2. Conductor :Cu or AL

3. Insulated :XLPE /PVC/PE

4. Armour :without armour or with armour (Steel tape armour,Steel wire armour ,Aluminum wire armour)

5. sheath : PVC ,PE

Application of PVC insulated cable

The cable is applied to fixed installation for rated voltage 0.6/1kv of power transmission and distribution line.

Applicable Standard of insulated cable :

IEC60502,,BS 5467,AS-NZS 5000.1,NF C 32-322,NF C33-210,CSA C22.2, ICEA S-95-658

Packing Material insulated cable :

Wooden drum, Iron-wooden drum, Steel drum

Single core pvc insulated cable pvc armoured cable PVC Insulated Cable

Conductor(mm2) Diameter(N/mm) overall(mm) weight(kg/km) Resistance(MΩ.km)
120 37/2.03 27.1 1819 0.153
150 37/2.25 29.2 2159 0.124
185 37/2.52 32.0 2643 0.0991
240 61/2.25 36.0 3414 0.0754
300 61/2.52 38.7 4124 0.0601
400 91/2.36 43.6 5300 0.0470
500 91/2.65 47.9 6536 0.0366
630 127/2.52 51.5 7932 0.0283
800 127/2.85 57.4 10020 0.0221
1000 127/3.20 64.2 12449 0.0176

Two-Core to Four-Core

Conductor(mm2) Diameter(N/mm) overall(mm) weight(kg/km) Resistance(MΩ.km)
2 3 4 2 3 4
1.5 1/1.38 12.8 13.3 14.1 329 358 405 12.10
2.5 1/1.78 13.8 14.3 15.2 386 426 475 7.41
4.0 7/0.85 17.1 17.8 19.3 616 683 807 4.61
6.0 7/1.04 18.4 19.3 20.9 712 829 967 3.08
10 7/1.35 21.0 22.0 23.6 963 1091 1278 1.83
16 7/1.70 23.5 24.9 27.5 1237 1443 1874 1.15
25 7/2.14 27.3 28.9 31.2 1755 2079 2487 0.727
35 14/1.8 24.8 27.1 30.3 1403 2149 2571 0.524
50 19/1.83 27.8 30.5 35.4 1791 2735 3392 0.387
70 27/1.83 30.4 35.0 39.2 2264 3714 4639 0.268
95 37/1.83 35.5 39.3 44.3 2919 4739 5888 0.193
120 30/2.30 38.0 42.2 49.3 3531 5690 7505 0.153
150 36/2.32 41.3 47.5 53.6 4231 7179 8930 0.124
185 45/2.30 46.4 51.9 59.0 5102 8387 10601 0.0991
240 60/2.26 51.2 57.8 65.7 6290 11049 13849 0.0754
300 61/2.52 56.4 63.2 72.0 7984 13471 16633 0.0601
400 61/2.90 61.9 69.6 81.3 10355 17833 22727 0.0470

Single core pvc insulated cable pvc armoured cable PVC Insulated Cable
