Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire
Specifications
Brand Name :
Huanghe
Model Number :
ZR-KVVR
Certification :
IOS OHSAS CCC IEC
Place of Origin :
China
MOQ :
100 Meters
Price :
0.1-200 USD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000 Meters Per Week
Packaging Details :
Wooden Drum
Conductor Material :
Copper
Jacket :
PVC
Insulation Material :
PVC
Application :
Instrumentation
Rated Voltage :
300/500V 450/750V
Temperature Degree :
75/90 Deg
Name :
Electric cable
Description

Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire

Product Description:

1) Conductor: Copper; Solid, Stranded & Flexible; 1~5 Cores

2) Insulation: Polyvinyl Chloride (PVC), Flame-Retardant or Halogen Free Polyolefin, Rubber, XLPE, etc.

3) Sheath: Non-Sheathed or PVC, PE, etc.

4) Features: Solid, Flexible, Round, Flat, Flame-Retardant, Fire-Resistant, Heat-Resistant, Low Smoke and Fume, Low Smoke Zero Halogen, High Temperature Resistant, etc.

5) Rated Voltage: 450/750V or 300/500V

6) Work Temperature: 70°C / 90°C / 105°C / 120°C / 150°C / 200°C / 250°C

7) Colors: Red, Blue, Brown, White, Black, Yellow, Two Colors, etc.

Low Voltage PVC Control Cable AWG ZR KVVR Fire Resistance Halogen Free Wire

Type Name Section Area(mm2) No. of Core Application Site

KVV

Copper Conductor,

PVC Insulated and Sheathed Control Cable

 0.75 1.0 1.5 2.5 2-16 Permanent installation indoors, in cable ditches or pipes
4 6 2-14
10 2-10

KVVP

 Copper Conductor, PVC Insulated and Sheathed,Braiding Shielded Control Cable 0.75 1.0 1.5 2.5 2-61

Permanent installation indoors, in cable ditches or pipes where shielding is required
4 6 2-14
10 2-10

KVVP2

 Copper Conductor, PVC Insulated and Sheathed,Copper-tape Screened Control Cable 0.75 1.0 1.5 2.5 4-10

Permanent installation indoors, in cable ditches or pipes where shielding is required
4 6 7-61
10 4-10
KVV22 Copper Conductor, PVC Insulated and Sheathed,Steel tape Armored Control Cable 0.75 1.0 1.5 2.5 7-61 Permanent installation indoors, in cable ditches, Be able to withstand stronger external mechanical force
4 6 4-14
10 4-14
KVVR Copper Conductor, PVC Insulated and Sheathed,Flexible Control Cable 0.5-2.5 4-61 Installation indoors where flexibility and mobility are required
KVVRP Copper Conductor, PVC Insulated and Sheathed,Braiding shielded Flexible Control Cable 0.5 0.75 1.0 4-61 Installation indoors where flexibility shielding and mobility are required
1.5 2.5 4-48
